JAUGE A CARBURANT LEVIER VDO 3-180OHMDAM MARINE
Ref. VDO226801015001Flotteur à levier réglable de 150 mm à 605 mm avec bride de fixation.
Flotteur à levier réglable de 150 mm à 605 mm avec bride de fixation.
Bracket kit for fuel gauge VDO atlas series including the installation required.
Adjustable lever fuel level indicator for tank 35 to 60cm depth.
Transmitter reserved for US probes of 240-33 ohms to know : teleflex - faria - mercury ...
Not compatible signal VDO 0-180 ohms: 90424E
Adjustable lever fuel level indicator for tank 10 to 60cm depth.
Resistance 240-33 ohms for instrumentation types : Teleflex, Mercury, Faria ... off VDO.
Metal parts in stainless steel.
Ceramic friction resistance, platinum contacts (up to four million guaranteed movements.
Patented system of delay of the mobile rod which cancels the tan/red effect.
S3 gauges are proposed in fixed dimensions measured from the top of the thread.The distance left free between the bottom of the tank and the bottom of the gauge increases the volume of the reserve.
Electric cable 30cm, 2 wire 0.75 mm2.
Electric resistance 0 to 180 Ohms (European).
Height head gauge mounted: 21 mm.
Operating temperature: -40°C to +70°C.
Power supply: 12/24 V.
Drilling: BSP R 1-1/4''.
External sensor head diameter: 54 mm.
For mounting with 5-hole flange use the reference 648310.
Fuel gauge with 5 screw attachment
JAUGE CARBURANT TUBULAIRE 300MM
Turbular fuel level sensor in stainless steel.38mm tube with Sureseal socket.
Its 38 mm diameter vertical tube contains a float inside, which measures a level of liquid.
The small holes at the top and bottom of the tube act as a deflector for the fuel flowing into the fuel tank, so that the float position remains stable in any state of the sea.
The sensors are made in different lengths ranging from 150 mm to 1200 mm
Please ensure that the selected length is at least 4 mm from the fuel tank base once installed.
Signal: 90-4 OHM
The deep-pipe level sensor is ideal for use in fuel tanks.
Its 38 mm diameter vertical tube contains a float inside, which measures a level of liquid.
The small holes at the top and bottom of the tube act as a deflector for the fuel flowing into the fuel tank, so that the float position remains stable in any state of the sea.
The sensors are made in different lengths ranging from 150 mm to 1200 mm
Please ensure that the selected length is at least 4 mm from the fuel tank base once installed.
Signal: 90-4 OHM
The deep-pipe level sensor is ideal for use in fuel tanks.
Its 38 mm diameter vertical tube contains a float inside, which measures a level of liquid.
The small holes at the top and bottom of the tube act as a deflector for the fuel flowing into the fuel tank, so that the float position remains stable in any state of the sea.
The sensors are made in different lengths ranging from 150 mm to 1200 mm
Please ensure that the selected length is at least 4 mm from the fuel tank base once installed.
Signal: 90-4 OHM
