Anti-siphon device with pressure relief valve without ventilation line. Supplied with connector, hose clamps and 4 m of 8 x 14 mm hose.

Can be used as an exhaust system or toilet.

Can be connected to pipes with internal diameters of 13, 19, 25 and 32 mm.

A 13mm diameter pipe can be directly fitted to the elbow fittings.

Size :

Width (mm): 50.

Length (mm): 98.

Height (mm): 162.

Materials:

Elbow, seat, valve and edge outlet: synthetic material.

Spring: Stainless steel.

The VETUS gas/water separator has a dual function. It separates the injected raw cooling water from the exhaust gases and also functions as a gooseneck. Particularly important for generator sets, the separator reduces exhaust noise and discharges the cooling water below the waterline, thus avoiding the characteristic splashing noise.

Features :

360º rotating pipe fittings for 50mm internal pipe diameters

50mm cooling water drain

Comes with a stainless steel (AISI 316) mounting bracket with synthetic straps

Indicator for VETUS exhaust temperature alarm, to be mounted with the XHSM or XHSH probes.

Dimension Ø 52 mm, total diameter 62 mm.

Mounting depth 40 mm.

Suitable for 24 Volt DC

Use the XHSM sensor in VETUS waterlocks with a pre-installed connection

Use the XHSH type sensor for mounting in the exhaust pipe

Combined with a silencer, the gooseneck saves installation time and space while maintaining the essential qualities of a good exhaust system with incredibly negligible back pressure. Prevents water from backing up the exhaust.

Suitable for pipes with an internal diameter of Ø 60 mm.

*Interchangeable connector for 65 mm hose (SET00025) available separately.

Fully rotating sections and pipe fittings ensure easy installation. Comes with a pipe fitting to connect the ventilation.

Features :

Capacity (liters): 10.

Length (mm): 285.3.

Width (mm): 160.

Height (mm): 646.4.

Airlock position: Vertical.

% Noise Reduction: 25.

VETUS long waterlock exhaust system for standard exhaust hose.

• Suitable for exhaust pipes with an inner diameter of Ø 40 mm

• Rotating inlet and outlet tips

• Comes with 1 safety strap

Capacity: 5.7L

A: 430 x 152 mm

B: 310mm

D: 40mm

Made from specially blended NAVIDURIN® composite, which is heat resistant up to 260°C.

While the NLP airlock design is already well known for its soundproofing characteristics, versatile installation options and extremely low back pressure, it now adds mechanical properties capable of meeting any challenge and placing it in a unique position on the market.

The thermal resistance to deformation under pressure is 250°C, almost double that of standard GRP materials, while the tensile and flexural strength are the same. What's more, all these advantages are available at a weight almost half that of the competition.

Features a 360° rotating body and endless connection options. Comes with floor and bulkhead mounting brackets and drain plugs for winter storage.

Suitable for 60mm exhaust system.

Features :

Capacity (liters): 10.

Length (mm): 515.

Width (mm): 210.

Height (mm): 362.

Airlock position: Vertical.

% Noise Reduction: 35.

Exhaust plug for water-injected exhaust systems, with rotating top. Made of corrosion-resistant synthetic materials. Excellent noise reduction.

Features :

• Excellent sound reduction

• Minimal back pressure

• Drain plug for winter storage

• Suitable for internal pipe diameters Ø 90, 102, 127, 152, 209 or 250 mm

• Capacities of 23, 75 or 130 liters

• Supplied with AISI 316 stainless steel clamping bands

• M12 thread purge

• Optional temperature sensor

Technical characteristics:

Capacity (liters): 75.

Water inlet pipe connection diameter (mm): 127.

Outlet pipe connection diameter (mm): 127.

Length (mm): 707.

Width (mm): 400.

Height (mm): 700.

Airlock position: Vertical.

% Noise Reduction: 25.
