Outboard boat engines - Power, reliability and easy handling

Moteur

Nombre de soupapes OHV monocylindre

Cylindrée (cc) 57

Alésage x course (mm) 45 x 36

Régime maxi (RPM) 5 000-6 000

Puissance nette du moteur (kW (PS)) 1.7 (2.3)

Refroidissement Refroidissement par air

Alimentation d'essence 1 carburateur

Allumage Transistorisé

Démarreur Manuel

Rapport d''embase 2.42

Embrayage centrifuge Oui

Hélice rotation Standard

Réglage d'assiette Manuel / Manuel 4 positions

Fonction

Dimensions

Hauteur du tableau (mm) 418

Poids à vide (kg) 13.5

Longueur (mm) 410

Largeur (mm) 280

Hauteur (mm) 945

Engine

Number of valves OHC 2 cylinders

Cylinder capacity (cc) 222

Bore x stroke (mm) 58 x 42

Maximum speed (RPM) 4500-5500

Net engine power (kW (PS)) 5.9 (6)

Cooling Water cooling (with thermostat)

Fuel supply 1 carburetor with accelerator pump

PGM-IG ignition (programmed electronic ignition)

Starter Electric starter

Exhaust Propeller Hub

Base ratio 2.33

Standard rotation propeller

Manual trim adjustment / Manual 5 positions

Function

Electric start Yes

Battery charging capacity (AMP.) 12A

Remote control Yes

DIMENSIONS

Empty weight (kg) 44.5

Length (mm) 610 (Tiller)

Width (mm) 345

Height (mm) 1235

Moteur

Nombre de soupapes OHV monocylindre

Cylindrée (cc) 57

Alésage x course (mm) 45 x 36

Régime maxi (RPM) 5 000-6 000

Puissance nette du moteur (kW (PS)) 1.7 (2.3)

Refroidissement Refroidissement par air

Alimentation d'essence 1 carburateur

Allumage Transistorisé

Démarreur Manuel

Rapport d''embase 2.42

Embrayage centrifuge Oui

Hélice rotation Standard

Réglage d'assiette Manuel / Manuel 4 positions

Fonction

Dimensions

Hauteur du tableau (mm) 571

Poids à vide (kg) 14

Longueur (mm) 410

Largeur (mm) 280

Hauteur (mm) 1110

The DF2.5 S is the smallest model of Suzuki 4-stroke engine.

Maintenance is simple and service intervals are moderate. It remains clean and economical to operate while meeting the strictest emissions standards. Its compact design and light weight make it the ideal choice for tenders, dinghies, and inflatables—it's as easy to maneuver as it is to store.

In addition, for higher transoms such as dinghies, old rigging, etc., the range is now enhanced with a long shaft model (on request).

Shaft or transom length:

- S:381mm

- L:508mm

Dry weight with battery cable without propeller or oil:

- S: 13.5 Kg

- L: 14 Kg

Manual start, tiller, forward/neutral.

Please note that during transport, the engine is delivered without oil in the crankcase. It is essential to fill up with the oil recommended by the manufacturer in order to start the engine: recommended engine oil, Motul 10W40 - 4-stroke - 2 liters

The manufacturer's warranty would not apply if this operation was not carried out.

Show features

Functionality

NMEA 2000 Yes

BLAST Yes

ECOmo Yes

VTEC yes

Remote control Yes

Engine

Number of valves OHC V6

Cylinder capacity (cc) 3583

Bore x stroke (mm) 89 x 96

Maximum RPM 5,000-6,000

Net engine power (kW (PS)) 183.9 (250)

Cooling Water cooling (with thermostat)

Electronic Fuel Feed (PGM-FI)

PGM-IG ignition (programmed electronic ignition)

Starter Electric starter

Exhaust Propeller Hub

Gear ratio 2.00:1

Standard rotation propeller

Electric trim adjustment

Function

Electric start Yes

Alternator output (AMP.) 90A

Battery charging capacity (AMP.) 60A

Remote control Yes

Dimensions

Table height (mm) 762

Empty weight (kg) 299

Length (mm) 920

Width (mm) 660

Height (mm) 1915

Show features

Functionality

NMEA 2000 Yes

BLAST Yes

ECOmo Yes

Y remote control

Engine

Number of valves DOHC - 4 cylinders

Cylinder capacity (cc) 2,354

Bore x stroke (mm) 87 x 99

Maximum RPM 5,000 - 6,000

Net engine power (kW (PS)) 99.3 (135)

Cooling Water cooling (with thermostat)

Electronic Fuel Feed (PGM-FI)

PGM-IG ignition (programmed electronic ignition)

Starter Electric starter

Exhaust Propeller Hub

Base report 2.14

Standard rotation propeller

Electric trim adjustment

Function

Electric start Yes

Alternator output (AMP.) 55A

Battery charging capacity (AMP.) 40A

Remote control Yes

Dimensions

Table height (mm) 635

Empty weight (kg) 224

Length (mm) 913

Width (mm) 618

Height (mm) 1815

The Suzuki DF6A outboard is a single-cylinder, 4-stroke engine with a displacement of no less than 138 cc.

Its excellent mid-range torque, combined with its low weight, allows for exceptionally high-quality acceleration. Its CDI system offers high ignition precision, optimizing its performance. It also incorporates a safety feature that prevents any risk of over-revving.

The tiller design allows for the most comfortable operating position possible and better weight distribution. Note some other key features of this lightweight motor which has a gear selector (forward, neutral, reverse), a 180° rotation (for excellent maneuverability), as well as a large carrying handle.

Shaft or transom length:

- S:381mm

- L:508mm

Dry weight with battery cable without propeller or oil:

- S: 23.5 Kg

- L: 24.5 Kg

Manual start, tiller, forward/neutral/reverse.

Please note that during transport, the engine is delivered without oil in the crankcase. It is essential to fill up with the oil recommended by the manufacturer in order to start the engine: recommended engine oil, Motul 10W40 - 4-stroke - 2 liters

The manufacturer's warranty would not apply if this operation was not carried out.

The Suzuki DF6A outboard is a single-cylinder, 4-stroke engine with a displacement of no less than 138 cc.

Its excellent mid-range torque, combined with its low weight, allows for exceptionally high-quality acceleration. Its CDI system offers high ignition precision, optimizing its performance. It also incorporates a safety feature that prevents any risk of over-revving.

The tiller design allows for the most comfortable operating position possible and better weight distribution. Note some other key features of this lightweight motor which has a gear selector (forward, neutral, reverse), a 180° rotation (for excellent maneuverability), as well as a large carrying handle.

Shaft or transom length:

- S:381mm

- L:508mm

Dry weight with battery cable without propeller or oil:

- S: 23.5 Kg

- L: 24.5 Kg

Manual start, tiller, forward/neutral/reverse.

Please note that during transport, the engine is delivered without oil in the crankcase. It is essential to fill up with the oil recommended by the manufacturer in order to start the engine: recommended engine oil, Motul 10W40 - 4-stroke - 2 liters

The manufacturer's warranty would not apply if this operation was not carried out.

Functionality

NMEA 2000 Yes

BLAST Yes

ECOmo Yes

Y remote control

Engine

Number of valves DOHC - 4 cylinders

Cylinder capacity (cc) 2,354

Bore x stroke (mm) 87 x 99

Maximum RPM 5,000 - 6,000

Net engine power (kW (PS)) 99.3 (135)

Cooling Water cooling (with thermostat)

Electronic Fuel Feed (PGM-FI)

PGM-IG ignition (programmed electronic ignition)

Starter Electric starter

Exhaust Propeller Hub

Base report 2.14

Standard rotation propeller

Electric trim adjustment

Function

Electric start Yes

Alternator output (AMP.) 55A

Battery charging capacity (AMP.) 40A

Remote control Yes

Dimensions

Table height (mm) 635

Empty weight (kg) 224

Length (mm) 913

Width (mm) 618

Height (mm) 1815

Functionality

NMEA 2000 Yes

BLAST Yes

ECOmo Yes

VTEC Yes

Remote control Yes

Engine

Number of valves 32 Valves

Cylinder capacity (cc) 4952

Bore x stroke (mm) 89 x 99.5

Maximum speed (RPM) 5000 - 6000

Net engine power (kW (PS)) 257.4 (350)

Cooling Water cooling (with thermostat)

Electronic Fuel Feed (PGM-FI)

PGM-IG ignition (programmed electronic ignition)

Starter Electric starter

Exhaust Propeller Hub

Gear ratio 1.79:1

Standard rotation propeller

Electric trim adjustment

Function

Electric start Yes

Alternator output (AMP.) 90A

Battery charging capacity (AMP.) 70A

Remote control Yes

Dimensions

Table height (mm) 762

Empty weight (kg) 360

Length (mm) 1121

Width (mm) 650

Height (mm) 2272

Functionality

NMEA 2000 Yes

BLAST Yes

ECOmo Yes

Y remote control

Engine

Number of valves DOHC - 4 cylinders

Cylinder capacity (cc) 2,354

Bore x stroke (mm) 87 x 99

Maximum RPM 5,000 - 6,000

Net engine power (kW (PS)) 84.6 (115)

Cooling Water cooling (with thermostat)

Electronic Fuel Feed (PGM-FI)

PGM-IG ignition (programmed electronic ignition)

Starter Electric starter

Exhaust Propeller Hub

Base report 2.14

Standard rotation propeller

Electric trim adjustment

Function

Electric start Yes

Alternator output (AMP.) 55A

Battery charging capacity (AMP.) 40A

Remote control Yes

Dimensions

Table height (mm) 508

Empty weight (kg) 221

Length (mm) 913

Width (mm) 618

Height (mm) 1815

Avec VTEC™, un arbre de 537 mm, une capacité de chargement de la batterie de 35 A ainsi que le relevage et l'inclinaison électriques.

Dimensions

Hauteur du tableau (mm) 537

Poids à vide (kg) 166

Longueur (mm) 746

Largeur (mm) 449

Hauteur (mm) 1 566

Functionality

NMEA 2000 Yes

BLAST Yes

ECOmo Yes

Y remote control

Engine

Number of valves SOHC 4 cylinders

Cylinder capacity (cc) 1496

Bore x stroke (mm) 73 x 89.4

Maximum RPM 5,000-6,000

Net engine power (kW (PS)) 58.8 (80)

Cooling Water cooling (with thermostat)

Electronic Fuel Feed (PGM-FI)

PGM-IG ignition (programmed electronic ignition)

Starter Electric starter

Exhaust Propeller Hub

Base ratio 2.33

Standard rotation propeller

Electric trim adjustment

Function

Electric start Yes

Alternator output (AMP.) 44A

Battery charging capacity (AMP.) 35A

Remote control Yes

Dimensions

Table height (mm) 537

Empty weight (kg) 165

Length (mm) 746

Width (mm) 449

Height (mm) 1,566

Fonctionnalité

NMEA 2000 Oui

BLAST Oui

ECOmo Oui

Commande à distance Y

Moteur

Nombre de soupapes DOHC - 4 cylindres

Cylindrée (cc) 2 354

Alésage x course (mm) 87 x 99

Régime maxi (RPM) 5 000 - 6 000

Puissance nette du moteur (kW (PS)) 99.3 (135)

Refroidissement Refroidissement par eau (avec thermostat)

Alimentation d'essence Electronique (PGM-FI)

Allumage PGM-IG (allumage électronique programmé)

Démarreur Démarreur électrique

Echappement Moyeu de l'hélice

Rapport d''embase 2.14

Hélice rotation Standard

Réglage d'assiette Electrique

Fonction

Démarrage électrique Oui

Sortie de l''alternateur (AMP.) 55A

Capacité de chargement de la batterie (AMP.) 40A

Commande à distance Oui

Dimensions

Hauteur du tableau (mm) 508

Poids à vide (kg) 218

Longueur (mm) 913

Largeur (mm) 618

Hauteur (mm) 1688
