List of products by brand VETUS

The most flexible wastewater hose available thanks to its smooth EPDM rubber material and the large number of turns.

The completely smooth inner surface of the pipe reduces back pressure in the engine.

Exhaust pipes with an inner diameter up to Ø 152 mm have a bend radius of 1.5 times the diameter. Exhaust pipes with an inner diameter greater than Ø 152 mm have a bend radius of twice the diameter. Resistant to temperatures between -30º + 100ºC with brief temperatures of 115ºC.

The SLANG type is approved by Lloyds Register and meets the requirements of SAE J2006 R2.

Features :

Weight (kg): 3.3.

Inner diameter (mm): 127.

Outer diameter (mm): 137.

Radius of curvature (mm): 191.

Suitable for: Exhaust.

Max. pressure (bar): 2.

Le tuyau d'évacuation des eaux usées le plus flexible disponible grâce à sa matière en caoutchouc EPDM lisse et en raison du grand nombre de spires.

La surface intérieure entièrement lisse du tuyau réduit la contre-pression dans le moteur.

Les tuyaux d'échappement d'un diamètre intérieur allant jusqu'à Ø 152 mm ont un rayon de courbure de 1,5 fois le diamètre. Les tuyaux d'échappement d'un diamètre intérieur supérieur à Ø 152 mm ont un rayon de courbure de deux fois le diamètre. Résistant à des températures comprises entre -30º + 100ºC avec des températures brèves de 115ºC.

Le type SLANG est approuvé par Lloyds Register et répond aux exigences de la norme SAE J2006 R2.

Caractéristiques :

Poids (kg) : 1,2.

Diamètre intérieur (mm) : 60.

Diamètre extérieur (mm) : 68.

Rayon de courbure (mm) : 90.

Convient pour : Échappement.

Pression max. (bar) : 3.3.

Couvercle pour filtre à eau de mer VETUS série 330. Le joint est inclus.

Seawater filter with the following characteristics:

- Water tap diameter 32mm

- Flow rate 143L / MIN

Seawater filter with the following characteristics:

- Water tap diameter 25mm

- Flow rate 91LK / MIN

Anti-siphon device with pressure relief valve without ventilation line. Supplied with connector, hose clamps and 4 m of 8 x 14 mm hose.

Can be used as an exhaust system or toilet.

Can be connected to pipes with internal diameters of 13, 19, 25 and 32 mm.

A 13mm diameter pipe can be directly fitted to the elbow fittings.

Size :

Width (mm): 50.

Length (mm): 98.

Height (mm): 162.

Materials:

Elbow, seat, valve and edge outlet: synthetic material.

Spring: Stainless steel.

Mushroom aerator in stainless steel (AISI 316), brightly polished, with mosquito net and synthetic counter flange, both in synthetic material. ISO 12216, Area II a.

These mushroom vents can be opened from the outside or inside using a built-in button.

Free passage area 30 cm²

Mushroom aerator in stainless steel (AISI 316), brightly polished, with mosquito net and synthetic counter flange, both in synthetic material. ISO 12216, Area II a.

These mushroom vents can be opened from the outside or inside using a built-in button.

Free passage area 76 cm²

The aerator can be screwed directly onto the hull or superstructure horizontally/vertically. Plastic base plate, water seal, 76 mm hose connection included. The free flow area is 38.5 cm².

The outer cover of this aerator is made of polished AISI 316 stainless steel and all other parts are made of synthetic materials.

The ideal solution for engine room ventilation openings

These translucent stainless steel (AISI 316) models with a polished, high-gloss cover cannot be closed, ensuring permanent ventilation. They are splash-proof and can be used in combination with electric exhaust fans (ref: FAN 12-14). Reliable, easy to maintain, and attractive.

Comes with mosquito net and interior finishing ring. Free passage area 24cm².

These stainless steel (AISI 316) models with a polished, high-gloss cover cannot be closed, ensuring permanent ventilation. They are splash-proof and can be used in combination with electric exhaust fans (ref: FAN 12-14). Reliable, easy to maintain, and attractive.

Comes with mosquito net and interior finishing ring. Free passage area 31.8cm².

Stainless steel deck filler (AISI 316)

The stainless steel deck filler with mirror-polished stainless steel waterproof cover.

Available for:

- Water

- Essence

- Diesel

- Black water (WC)

Technical characteristics:

Cap (Q) diameter: 86.5 mm

Type: Key

Liquid: Diesel

Pipe (U) diameter: 38 mm

Cutout (B) diameter: 51 mm

Length (H): 82.5 mm

Seawater filter with the following characteristics:

- Water connection diameter 19mm

- Flow rate 51L / MIN

The VETUS flexible cable gland used in this system has double lip seals to double the safety and guarantee watertightness.

Shaft diameter: 35 mm

Stern tube diameter: 56 mm

Width: 112 mm

Length: 145 mm

Anode for Vetus bow thruster types 35, 45 or 55 KGF.

mounting kit included.

Exhaust and cooling hose adapter allowing the connection of hoses with different diameters.

Exhaust and cooling hose adapter allowing the connection of hoses with different diameters.

Dispositif anti-siphon sans soupape avec conduite de ventilation. Fournis avec raccord, colliers de serrage et 4 m de tuyau de 8 x 14mm.

Peut être utilisé comme système d'échappement ou toilettes.

Peut être raccordé à des tuyaux de diamètres intérieurs de 13, 19, 25 et 32 ??mm.

Un tuyau de 13 mm de diamètre peut être directement monté sur les raccords du coude.

Taille :

Largeur (mm) : 50.

Longueur (mm) : 98.

Hauteur (mm) : 162.

Matériaux :

Coude, assise, soupape et sortie de bordages : matière synthétique.

Ressort : Inox.

Once your boat's engine has been stopped, with the correct volume capacity selected, the VETUS waterlock will ensure that water does not return to the engine. All VETUS water pots are equipped with a drain plug for winter storage.

Suitable for exhaust pipes with an inner diameter of Ø 40 mm.

Capacity: 4.3L

A: 372 x 110 mm

B: 211mm

D: 40mm

1 adjustable entrance

1 fixed output

VETUS long waterlock exhaust system for standard exhaust hose.

• Suitable for exhaust pipes with an inner diameter of Ø 45 mm

• Rotating inlet and outlet tips

• Comes with 1 safety strap

Capacity: 5.7L

A: 430 x 152 mm

B: 310mm

D: 45mm
