This high-quality synthetic tank for drinking water is supplied with an electric pump that automatically starts when the pressure in the system drops (for example, when a tap is opened).

Installing a DWS tank saves valuable time, as all that's required is connecting the pipes and power supply. This high-end drinking water system offers a high degree of ease of use.

An inspection cover for cleaning the inside of the tank is also fitted.

All fittings for the 38mm suction and 16mm vent diameter filler pipe are supplied pre-installed, along with a filter in the suction line and a float sensor for connecting a level gauge.

Features :

Tank volume (liter): 88.

Voltage: (v): 24.

Filling diameter (mm): 38.

Event Diameter (mm): 16.

Drain diameter (mm): 13.

Pump flow rate (l/min): 13.2

Pressure (Bar): 3.10.

Length (mm): 930.

Depth (mm): 400.

Height (mm): 400.

This high-quality synthetic tank for drinking water is supplied with an electric pump that automatically starts when the pressure in the system drops (for example, when a tap is opened).

Installing a DWS tank saves valuable time, as all that's required is connecting the pipes and power supply. This high-end drinking water system offers a high degree of ease of use.

An inspection cover for cleaning the inside of the tank is also fitted.

All fittings for the 38mm suction and 16mm vent diameter filler pipe are supplied pre-installed, along with a filter in the suction line and a float sensor for connecting a level gauge.

Features :

Tank volume (liter): 88.

Voltage: (v): 12.

Filling diameter (mm): 38.

Event Diameter (mm): 16.

Drain diameter (mm): 13.

Pump flow rate (l/min): 13.2

Pressure (Bar): 3.10.

Length (mm): 930.

Depth (mm): 400.

Height (mm): 400.

This high-quality synthetic tank for drinking water is supplied with an electric pump that automatically starts when the pressure in the system drops (for example, when a tap is opened).

Installing a DWS tank saves valuable time, as all that's required is connecting the pipes and power supply. This high-end drinking water system offers a high degree of ease of use.

An inspection cover for cleaning the inside of the tank is also fitted.

All fittings for the 38mm suction and 16mm vent diameter filler pipe are supplied pre-installed, along with a filter in the suction line and a float sensor for connecting a level gauge.

Features :

Tank volume (liter): 61.

Voltage: (v): 24.

Filling diameter (mm): 38.

Event Diam (mm): 16.

Drain diameter (mm): 13.

Pump flow rate (l/min): 13.2

Pressure (Bar): 3.10.

Length (mm): 780.

Depth (mm): 350.

Height (mm): 400.

This high-quality synthetic tank for drinking water is supplied with an electric pump that automatically starts when the pressure in the system drops (for example, when a tap is opened).

Installing a DWS tank saves valuable time, as all that's required is connecting the pipes and power supply. This high-end drinking water system offers a high degree of ease of use.

An inspection cover for cleaning the inside of the tank is also fitted.

All fittings for the 38mm suction and 16mm vent diameter filler pipe are supplied pre-installed, along with a filter in the suction line and a float sensor for connecting a level gauge.

Features :

Tank volume (liter): 61.

Voltage: (v): 12.

Filling diameter (mm): 38.

Event Diam (mm): 16.

Drain diameter (mm): 13.

Pump flow rate (l/min): 13.2

Pressure (Bar): 3.10.

Length (mm): 780.

Depth (mm): 350.

Height (mm): 400.

This high-quality synthetic tank for drinking water is supplied with an electric pump that automatically starts when the pressure in the system drops (for example, when a tap is opened).

Installing a DWS tank saves valuable time, as all that's required is connecting the pipes and power supply. This high-end drinking water system offers a high degree of ease of use.

An inspection cover for cleaning the inside of the tank is also fitted.

All fittings for the 38mm suction and 16mm vent diameter filler pipe are supplied pre-installed, along with a filter in the suction line and a float sensor for connecting a level gauge.

Features :

Tank volume (liter): 42.

Voltage: (v): 24.

Filling diameter (mm): 38.

Event Diameter (mm): 16.

Drain diameter (mm): 13.

Pump flow rate (l/min): 13.2

Pressure (Bar): 3.10.

Length (mm): 610.

Depth (mm): 350.

Height (mm): 400.

This high-quality synthetic tank for drinking water is supplied with an electric pump that automatically starts when the pressure in the system drops (for example, when a tap is opened).

Installing a DWS tank saves valuable time, as all that's required is connecting the pipes and power supply. This high-end drinking water system offers a high degree of ease of use.

An inspection cover for cleaning the inside of the tank is also fitted.

All fittings for the 38mm suction and 16mm vent diameter filler pipe are supplied pre-installed, along with a filter in the suction line and a float sensor for connecting a level gauge.

Features :

Tank volume (liter): 42.

Voltage: (v): 12.

Filling diameter (mm): 38.

Event Diameter (mm): 16.

Drain diameter (mm): 13.

Pump flow rate (l/min): 13.2

Pressure (Bar): 3.10.

Length (mm): 610.

Depth (mm): 350.

Height (mm): 400.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 50.

External Diam (mm): 60.

Weight (kg/m) 1.20.

Max pressure (bar): 3.

Curve (mm): 125.

Roll length (m): 10.

Suitable HCHD(S) collar: HCHD(S)0359.

Suitable HCS collars: HCS50.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 45.

External Diam (mm): 55.

Weight (kg/m) 1.10.

Max pressure (bar): 3.

Curve (mm): 105.

Roll length (m): 10.

HCHD(S) collar suitable: HCHD(S)051 - HCHD(S)055.

Suitable HCS collars: HCS40 - HCS50.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 40.

External Diam (mm): 49.

Weight (kg/m) 0.87.

Max pressure (bar): 3.

Curve (mm): 95.

Roll length (m): 10.

Suitable HCHD(S) collar: HCHD(S)047.

Suitable HCS collars: HCS32 - HCS40.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 38.

External Diam (mm): 47.

Weight (kg/m) 0.80.

Max pressure (bar): 4.

Curve (mm): 90.

Roll length (m): 30.

HCHD(S) collar suitable: HCHD(S)043 - HCHD(S)047.

Suitable HCS collars: HCS32 - HCS40.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 35.

External Diam (mm): 44.

Weight (kg/m) 0.73.

Max pressure (bar): 4.

Curve (mm): 80.

Roll length (m): 30.

Suitable HCHD(S) collar: HCHD(S)043.

Suitable HCS collars: HCS32 - HCS40.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 32.

External Diam (mm): 40.

Weight (kg/m) 0.56.

Max pressure (bar): 4.5.

Curve (mm): 75.

Roll length (m): 30.

HCHD(S) collar suitable: HCHD(S)037 - HCHD(S)0340.

Suitable HCS collars: HCS32 - HCS40.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 30.

External Diam (mm): 38.

Weight (kg/m) 0.60.

Max pressure (bar): 4.5.

Curve (mm): 70.

Roll length (m): 30.

Suitable HCHD(S) collar: HCHD(S)037.

Suitable HCS collars: HCS25 - HCS32.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 28.

External Diam (mm): 36.

Weight (kg/m) 0.57.

Max pressure (bar): 4.5.

Curve (mm): 66.

Roll length (m): 30.

Suitable HCHD(S) collar: HCHD(S)034.

Suitable HCS collars: HCS25 - HCS32.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 25.

External Diam (mm): 33.

Weight (kg/m) 0.53.

Max pressure (bar): 5.

Curve (mm): 60.

Roll length (m): 30.

Suitable HCS collars: HCS25 - HCS32.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 19.

External Diam (mm): 26.

Weight (kg/m) 0.32.

Max pressure (bar): 5.

Curve (mm): 50.

Roll length (m): 30.

Suitable HCS collars: HCS16 - HCS20- HCS25.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 16.

External Diam (mm): 22.

Weight (kg/m) 0.24.

Max pressure (bar): 6.

Curve (mm): 35.

Roll length (m): 30.

Suitable HCS collar: HCS16 - HCS20.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 12.

External Diam (mm): 18.

Weight (kg/m) 0.18.

Max pressure (bar): 7.

Curve (mm): 25.

Roll length (m): 30.

Suitable HCS collar: HCS12.

This hose is made of transparent PVC with a spiral inlay and is suitable for transport.

drinking water and grey water on board, suction or pressure

Inner Diam (mm): 10.

External Diam (mm): 16.

Weight (kg/m) 0.16.

Max pressure (bar): 7.

Suitable HCS collar: HCS12.

Curve (mm): 20.

Roll length (m): 30.

Mushroom aerator in stainless steel (AISI 316), brightly polished, with mosquito net and synthetic counter flange, both in synthetic material. ISO 12216, Area II a.

These mushroom vents can be opened from the outside or inside using a built-in button.

Free passage area 45 cm²

The aerator can be screwed directly onto the hull or superstructure horizontally/vertically. Plastic base plate, water seal, 75 mm hose connection included. The free flow area is 30 cm².

The outer cover of this aerator is made of polished AISI 316 stainless steel and all other parts are made of synthetic materials. When installed, no screws are visible.

The ideal solution for engine room ventilation openings.

The aerator can be screwed directly onto the hull or superstructure horizontally/vertically. Plastic base plate, water seal, 100 mm hose connection included. The free flow area is 41 cm².

The outer cover of this aerator is made of polished AISI 316 stainless steel and all other parts are made of synthetic materials. When installed, no screws are visible.

The ideal solution for engine room ventilation openings.

Ces modèles en acier inoxydable (AISI 316) avec un couvercle brillant poli peuvent être fermés et rendu absolument étanche.

Lorsqu'ils sont ouverts ils offrent une ventilation constante et reste toujours à l'abri de la pluie et des éclaboussures.

Fiables, faciles à entretenir et beaux.

Livré avec moustiquaire intégral ainsi qu'une bague de finition synthétique. Surface de passage libre 20cm².

Specially designed for boats, this barely audible electric fan is designed for living rooms, cabins, hallways, and toilets and is also ideal for extracting heat near a refrigerator. It can be installed in ceilings and bulkheads. With its long-life motor, it can operate for at least 50,000 hours.

It is recommended that each zone have an air exchange rate of 3 to 4 times per hour.

It can be used in combination with VETUS UFO and UFOTRANS deck fans.

Specifications:

• Available in 12 or 24 Volt

• Capacity 72 m3 / hour

• Has a 2-speed switch

Technical characteristics:

Voltage (V): 24.

Capacity (m³/minute): 1.2.

Static pressure: 6 mm H2O.

Specially designed for boats, this barely audible electric fan is designed for living rooms, cabins, hallways, and toilets and is also ideal for extracting heat near a refrigerator. It can be installed in ceilings and bulkheads. With its long-life motor, it can operate for at least 50,000 hours.

It is recommended that each zone have an air exchange rate of 3 to 4 times per hour.

It can be used in combination with VETUS UFO and UFOTRANS deck fans.

Specifications:

• Available in 12 or 24 Volt

• Capacity 72 m3 / hour

• Has a 2-speed switch

Technical characteristics:

Voltage (V): 12.

Capacity (m³/minute): 1.2.

Static pressure: 6 mm H2O.
