List of products by brand VETUS

Replacement mosquito net for porthole type PM131 and PM133.

Replacement mosquito net for porthole type PM121 and PM123.

Replacement mosquito net for porthole type PM111 and PM113.

Stainless steel portholes - Type PMS (AI)

VETUS offers a range of portholes made of stainless steel (AISI 316) in categories AI and AII.

They come with a stainless steel (AISI 316) inner frame, 8mm "smoked" acrylic glazing and a mosquito net on anodized aluminum frame.

These portholes are suitable for a structure thickness of 3 to 18mm.

Screws for different wall thicknesses can be ordered separately.

Features :

External dimensions A x B (in mm): 346 x 199.

Cut-out dimensions C x D (in mm): 322 x 177.

Replacement mosquito net: HOR23S.

Replacement mosquito net for porthole type PMS24A2 and PMS24A1.

Replacement mosquito net for porthole type PMS23A2 and PMS23A1.

Medium-strength portholes - Type PX and PXF (AIII)

These portholes are suitable for use on the roof side.

They come with a 10mm smoked unframed opening glass pane.

The clamp-type installation ensures that no fasteners are visible from the inside or outside.

The portholes can be kept open in any position thanks to the friction hinges.

In the closed position, two buttons ensure watertightness. They come standard with a mosquito net.

The porthole can be installed on a surface with a minimum thickness of 2 mm and a maximum thickness of 18 mm.

Features :

External dimensions A x B (in mm): 522 X 219.

Cut-out dimensions C x D (in mm): 498 X 195.

Replacement mosquito net: HORPXF.

Medium-strength portholes - Type PX and PXF (AIII)

These portholes are suitable for use on the roof side.

They come with a 10mm smoked unframed opening glass pane.

The clamp-type installation ensures that no fasteners are visible from the inside or outside.

The portholes can be kept open in any position thanks to the friction hinges.

In the closed position, two buttons ensure watertightness. They come standard with a mosquito net.

The porthole can be installed on a surface with a minimum thickness of 2 mm and a maximum thickness of 18 mm.

Features :

External dimensions A x B (in mm): 544 X 217.

Cut-out dimensions C x D (in mm): 520 X 193.

Replacement mosquito net: HOR47.

Medium-strength portholes - Type PX and PXF (AIII)

These portholes are suitable for use on the roof side.

They come with a 10mm smoked unframed opening glass pane.

The clamp-type installation ensures that no fasteners are visible from the inside or outside.

The portholes can be kept open in any position thanks to the friction hinges.

In the closed position, two buttons ensure watertightness. They come standard with a mosquito net.

The porthole can be installed on a surface with a minimum thickness of 2 mm and a maximum thickness of 18 mm.

Features :

External dimensions A x B (in mm): 441 X 179.

Cut-out dimensions C x D (in mm): 417 X 155.

Replacement mosquito net: HOR45.

Hublots moyennement renforcés - Type PX et PXF (AIII)

Ces hublots sont adaptés pour une utilisation côté roof.

Ils sont livrés avec une vitre d'ouverture non encadrée de couleur fumée de 10 mm sans cadre.

L'installation de type pince garantit qu'aucune fixation n'est visible de l'intérieur ou de l'extérieur.

Les hublots peuvent être maintenus ouverts dans n'importe quelle position grâce aux charnières à friction.

En position fermée, 2 boutons assurent l'étanchéité. Ils sont fournis en standard avec une moustiquaire.

Le hublot peut être installé sur une surface d'une épaisseur minimale de 2 mm et d'une épaisseur maximale de 18 mm.

Caractéristiques :

Dimensions extérieures A x B (en mm) : 492 X 196.

Dimensions découpe C x D (en mm) : 468 X 172.

Moustiquaire de remplacement : HOR46.

Replacement mosquito net for PXF type porthole with a depth of 219mm.

Replacement mosquito net for PX47 type porthole.

Replacement mosquito net for PX46 type porthole.

Replacement mosquito net for PX45 type porthole.

Ultra-thin portholes - Type PZ (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 451 x 274.

Cut-out dimensions C x D (in mm): 427 x 250.

Cutting radius R (in mm): 54.

Replacement mosquito net: HOR67.

Ultra-thin portholes - Type PZ (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 399 x 234.

Cut-out dimensions C x D (in mm): 375 x 210.

Cutting radius R (in mm): 54.

Replacement mosquito net: HOR66.

Ultra-thin portholes - Type PZ (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 397 x 197.

Cut-out dimensions C x D (in mm): 373 x 173.

Cutting radius R (in mm): 61.

Replacement mosquito net: HOR64.

Hublot ultra minces - Type PZ (AI)

Les hublots de la série PL sont si affleurants qu'ils ressemblent à du verre fritté et conviennent pour être installés dans

une variété de matériaux.

Malgré leur faible épaisseur, ils sont toujours homologués CE pour la zone de localisation AI, ce qui signifie qu'ils sont utilisables pour tous les domaines répertoriés dans la norme ISO ! Un bord en aluminium très plat combiné au mécanisme de serrage assure un hublot à profil très bas même lorsqu'il est monté dans le verre lui-même. Ils sont également équipés des nouveaux boutons ergonomiques.

Ces hublots ultra minces peuvent accepter des épaisseurs de panneaux allant de 2 à 20 mm. L'intérieur du profil de serrage peut être fini avec la garniture fournie. Tous

les hublots PL sont en aluminium noir satiné à la mode avec de l'acrylique teinté « fumée noire » de 10 mm d'épaisseur pour un look haut de gamme.

Caractéristiques :

Dimensions extérieures A x B (en mm) : 399 x 190.

Dimensions de découpe C x D (en mm) : 375 x 166.

Radius découpe R (en mm) : 54.

Moustiquaire de remplacement : HOR65.

Ultra-thin portholes - Type PZ (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 622 x 197.

Cut-out dimensions C x D (in mm): 598 x 173.

Cutting radius R (in mm): 61.

Replacement mosquito net: HOR63.

Ultra-thin portholes - Type PZ (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 368 x 179.

Cut-out dimensions C x D (in mm): 344 x 155.

Cutting radius R (in mm): 61.

Replacement mosquito net: HOR62.

Ultra-thin portholes - Type PZ (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 301 x 164.

Cut-out dimensions C x D (in mm): 277 x 140.

Cutting radius R (in mm): 54.

Replacement mosquito net: HOR61.

Replacement mosquito net for porthole type PZ671 and PZ673.

Replacement mosquito net for porthole type PZ661 and PZ663.
