List of products by brand VETUS

Suitable for exhaust pipe with internal diameter of Ø 60 mm.

The gooseneck raises the exhaust line above the waterline and provides additional reduction of the

noise. The outlet fits directly onto all VETUS rubber exhaust outlets.

Features :

Water inlet pipe connection diameter (mm): 60.

Outlet pipe connection diameter (mm): 60.

Length (mm): 182.

Width (mm): 135.

Height (mm): 502.

Suitable for exhaust pipe with internal diameter of Ø 50 mm.

The gooseneck raises the exhaust line above the waterline and provides additional reduction of the

noise. The outlet fits directly onto all VETUS rubber exhaust outlets.

Features :

Water inlet pipe connection diameter (mm): 50.

Outlet pipe connection diameter (mm): 50.

Length (mm): 182.

Width (mm): 135.

Height (mm): 502.

Suitable for exhaust pipe with internal diameter of Ø 45 mm.

The gooseneck raises the exhaust line above the waterline and provides additional reduction of the

noise. The outlet fits directly onto all VETUS rubber exhaust outlets.

Features :

Water inlet pipe connection diameter (mm): 45.

Outlet pipe connection diameter (mm): 45.

Length (mm): 182.

Width (mm): 135.

Height (mm): 502.

Suitable for exhaust pipe with internal diameter of Ø 40 mm.

The gooseneck raises the exhaust line above the waterline and provides additional reduction of the

noise. The outlet fits directly onto all VETUS rubber exhaust outlets.

Features :

Water inlet pipe connection diameter (mm): 40.

Outlet pipe connection diameter (mm): 40.

Length (mm): 182.

Width (mm): 135.

Height (mm): 502.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 90.

Outlet pipe connection diameter (mm): 90.

Length (mm): 210.

Width (mm): 300.

Height (mm): 525.

Airlock position: Horizontal.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 90.

Outlet pipe connection diameter (mm): 110.

Length (mm): 210.

Width (mm): 300.

Height (mm): 525.

Airlock position: Horizontal.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 75.

Outlet pipe connection diameter (mm): 75.

Length (mm): 155.

Width (mm): 235.

Height (mm): 500.

Airlock position: Horizontal.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 65.

Outlet pipe connection diameter (mm): 75.

Length (mm): 155.

Width (mm): 235.

Height (mm): 500.

Airlock position: Horizontal.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 65.

Outlet pipe connection diameter (mm): 65.

Length (mm): 155.

Width (mm): 235.

Height (mm): 500.

Airlock position: Horizontal.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 152.

Outlet pipe connection diameter (mm): 152.

Length (mm): 275.

Width (mm): 380.

Height (mm): 565.

Airlock position: Vertical.

% Noise Reduction: 15.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 127.

Outlet pipe connection diameter (mm): 127.

Length (mm): 275.

Width (mm): 380.

Height (mm): 565.

Airlock position: Vertical.

% Noise Reduction: 15.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 110.

Outlet pipe connection diameter (mm): 110.

Length (mm): 210.

Width (mm): 300.

Height (mm): 525.

Airlock position: Horizontal.

Plastic gooseneck for marine exhaust systems with water injection. Supplied with stainless steel (AISI 316) mounting brackets.

Features :

Water inlet pipe connection diameter (mm): 102.

Outlet pipe connection diameter (mm): 102.

Length (mm): 210.

Width (mm): 300.

Height (mm): 525.

Airlock position: Vertical.

% Noise Reduction: 15.

Replacement valve for the AIRVENTV range.

Replacement kit (set of 5) of valve for ASDV model.

Anti-siphon elbow without valve and with ventilation pipe, connection 13 - 32 mm.

Can be used as a drainage system or toilet.

Interchangeable with the AIRVENT type and have the same fixing center distances

Comes complete with fitting, hose clamps and 2m of hose. Non-valve anti-siphon elbows must be fitted with a ventilation pipe.

The air vent fitting rotates 360°. (Includes a 2 m hose and skin fittings). In addition, the valve can be serviced without removing the vent from the wall and no tools are required for this. For replacement, a set of 5 valves is available as a spare part.

A 13 mm diameter flexible hose can be directly connected to the elbow connections

Can be connected to pipes with inner diameters of 13, 19, 25 and 32 mm.

Size :

Width (mm): 68.

Length (mm): 96.

Height (mm): 133.

Anti-siphon elbow with valve and hose. With 4m of 8 x 14mm ventilation hose, suitable for 38mm pipes. Ideal for toilets or holding tanks installed below the waterline.

Interchangeable with AIRVENT type thanks to the same fixing hole centers.

The air bleed fitting rotates 360°. (Includes 2m hose and skin fittings)

A 38 mm diameter flexible hose can be connected directly to the elbow connections. Mount each hose connection with a stainless steel clamp.

Size :

Length (mm): 129.

Width (mm): 48.

Height (mm): 107.

Pipe connection diameter (mm): 38.

Anti-siphon elbow without valve and with hose. With 4m of 8 x 14mm ventilation hose, suitable for 38mm pipes. Ideal for toilets or holding tanks installed below the waterline.

The air bleed fitting rotates 360°. (Includes 2m hose and skin fittings)

A 38 mm diameter flexible hose can be connected directly to the elbow connections. Mount each hose connection with a stainless steel clamp.

Size :

Length (mm): 129.

Height (mm): 107.

Pipe connection diameter (mm): 38.

The VETUS gas/water separator has a dual function. It separates the injected raw cooling water from the exhaust gases and also functions as a gooseneck. Particularly important for generator sets, the separator reduces exhaust noise and discharges the cooling water below the waterline, thus avoiding the characteristic splashing noise.

With a 20 litre capacity and a 75mm connection, this separator is suitable for engines up to 125hp.

The splitter's compact design ensures it will fit most boats.

Features :

Rotating pipe fittings for easy installation

75mm cooling water drain

Comes with a stainless steel (AISI 316) mounting bracket with synthetic straps

The VETUS gas/water separator has a dual function. It separates the injected raw cooling water from the exhaust gases and also functions as a gooseneck. Particularly important for generator sets, the separator reduces exhaust noise and discharges the cooling water below the waterline, thus avoiding the characteristic splashing noise.

Features :

360º rotating pipe fittings for 75mm internal pipe diameters

50mm cooling water drain

Comes with a stainless steel (AISI 316) mounting bracket with synthetic straps

The VETUS gas/water separator has a dual function. It separates the injected raw cooling water from the exhaust gases and also functions as a gooseneck. Particularly important for generator sets, the separator reduces exhaust noise and discharges the cooling water below the waterline, thus avoiding the characteristic splashing noise.

Features :

360º rotating pipe fittings for 50mm internal pipe diameters

50mm cooling water drain

Comes with a stainless steel (AISI 316) mounting bracket with synthetic straps

The VETUS gas/water separator has a dual function. It separates the injected raw cooling water from the exhaust gases and also functions as a gooseneck. Particularly important for generator sets, the separator reduces exhaust noise and discharges the cooling water below the waterline, thus avoiding the characteristic splashing noise.

Features :

360º rotating pipe fittings for 50mm internal pipe diameters

38mm cooling water drain

Comes with a stainless steel (AISI 316) mounting bracket with synthetic straps

The VETUS gas/water separator has a dual function. It separates the injected raw cooling water from the exhaust gases and also functions as a gooseneck. Particularly important for generator sets, the separator reduces exhaust noise and discharges the cooling water below the waterline, thus avoiding the characteristic splashing noise.

Features :

360º rotating pipe fittings for 45mm internal pipe diameters

38mm cooling water drain

Comes with a stainless steel (AISI 316) mounting bracket with synthetic straps

The VETUS gas/water separator has a dual function. It separates the injected raw cooling water from the exhaust gases and also functions as a gooseneck. Particularly important for generator sets, the separator reduces exhaust noise and discharges the cooling water below the waterline, thus avoiding the characteristic splashing noise.

Features :

360º rotating pipe fittings for 40mm internal pipe diameters

38mm cooling water drain

Comes with a stainless steel (AISI 316) mounting bracket with synthetic straps

Once your boat's engine has been stopped, with the correct volume capacity selected, the VETUS waterlock will ensure that water does not return to the engine. All VETUS water pots are equipped with a drain plug for winter storage.

Suitable for exhaust pipes with an inner diameter of Ø 45 mm.

Capacity: 4.3L

A: 372 x 110 mm

B: 211mm

D: 45mm

1 adjustable entrance

1 fixed output
