List of products by brand VETUS

This pressurized water system ensures a constant flow in the boat's freshwater circuit. It is comparable to a domestic tap water system. The tank and its pressurized membrane relieve the pump motor by saving it from having to start each time water is drawn. This system ensures a constant water flow, saving energy and minimizing noise.

The pressurized water units of HF type systems meet EMC requirements.

Comes with:

• Self-priming pump

• Filter

• Pressure gauge

• Mounting bracket

Features :

Width (mm): 200.

Height (mm): 324.

Length (mm): 365.

Voltage (V): 24.

Capacity (liters/min): 12.5.

Tank capacity (liters): 8.

Weight (kg): 6.2.

Pipe connection diameter (mm): 13.

Max. pressure (bar): 2.5.

Max. suction height (m): 3.

The HWHOSE type is made of EPDM rubber, reinforced with synthetic fabric. This hose is suitable for drinking water and is resistant to temperatures from -30 to +160 ºC.

Ideal for use with water heaters and hot water systems

Features :

Radius of curvature (mm): 95.

Max. pressure (bar): 8.

Weight (kg): 0.36.

Inner diameter (mm): 13.

Outer diameter (mm): 23.

Roll length (m): 10.

HCS stainless steel collar W4: HCS20.

The HWHOSE type is made of EPDM rubber, reinforced with synthetic fabric. This hose is suitable for drinking water and is resistant to temperatures from -30 to +160 ºC.

Ideal for use with water heaters and hot water systems

Features :

Bend radius (mm): 110.

Max. pressure (bar): 8.

Weight (kg): 0.40.

Inner diameter (mm): 16.

Outer diameter (mm): 26.

Roll length (m): 10.

HCS stainless steel collar W4: HCS25.

This pressurized water system ensures a constant flow in the boat's freshwater circuit. It is comparable to a domestic tap water system. The tank and its pressurized membrane relieve the pump motor by saving it from having to start each time water is drawn. This system ensures a constant water flow, saving energy and minimizing noise.

They have an adjustable pressure switch, a pressure gauge (manometer) and a non-return valve.

The pressurized water units of HF type systems meet EMC requirements.

Features :

Width (mm): 200.

Height (mm): 324.

Length (mm): 404.

Voltage (V): 12.

Capacity (liters/min): 12.5.

Tank capacity (liters): 8.

Weight (kg): 8.2.

Pipe connection diameter (mm): 13.

Max. pressure (bar): 2.5.

Max. suction height (m): 3.

This pressurized water system ensures a constant flow in the boat's freshwater circuit. It is comparable to a domestic tap water system. The tank and its pressurized membrane relieve the pump motor by saving it from having to start each time water is drawn. This system ensures a constant water flow, saving energy and minimizing noise.

They have an adjustable pressure switch, a pressure gauge (manometer) and a non-return valve.

The pressurized water units of HF type systems meet EMC requirements.

Features :

Width (mm): 200.

Height (mm): 324.

Length (mm): 404.

Voltage (V): 24.

Capacity (liters/min): 12.5.

Tank capacity (liters): 8.

Weight (kg): 8.2.

Pipe connection diameter (mm): 13.

Max. pressure (bar): 2.5.

Max. suction height (m): 3.

Innovative inspection hatch with a robust design. The ILT is an innovative inspection hatch that makes it easy to open, inspect, and clean the tank, even after it has been closed for a long time.

The inspection port has a counter flange and silicone rubber that are inserted into a Ø 159 mm hole in the tank. Suitable for tanks with a wall thickness of 4 to 10 mm.

Simply tighten the five supplied bolts that compress the silicone rubber to ensure a perfect seal.

The "insert-clamp" design simplifies installation, making drilling a Ø 159 hole the hardest part of the installation. The black blind plate can be replaced with various connection kits.

Innovative inspection hatch with a robust design. The ILT is an innovative inspection hatch that makes it easy to open, inspect, and clean the tank, even after it has been closed for a long time.

The inspection port has a counter flange and silicone rubber that are inserted into a Ø 159 mm hole in the tank. Suitable for tanks with a wall thickness of 0.8 to 4 mm.

Simply tighten the five supplied bolts that compress the silicone rubber to ensure a perfect seal.

The "insert-clamp" design simplifies installation, making drilling a Ø 159 hole the hardest part of the installation. The black blind plate can be replaced with various connection kits.

90 degree elbow filling connection Ø 38 mm for ILTCOND drinking water connection kit.

To make opening and closing ILT lids easy and hassle-free, a well-designed key to facilitate the movement of stubborn lids.

Keeping water fresh and preventing bacteria growth can be tricky, but a wide opening will help get the job done.

Periodic cleaning of all connections and of course the tank itself will be a much easier job if it can be done in a minimum of time.

Supplied with:

Fresh water filling connection Ø 38 mm.

Fresh water suction connection Ø 13 mm.

Ventilation connection Ø 16.

5-hole SAE flange tank level sensor connection.

Features :

Cutting diameter (mm): 159.

Diameter (mm): 120.

Red interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 205.

B (in mm): 75.

C (in mm): 123.

D (in mm): 22.

Free passage area (in cm²) / 44.2.

Material: Stainless steel (AISI 316).

White interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 205.

B (in mm): 75.

C (in mm): 123.

D (in mm): 22.

Free passage area (in cm²) / 44.2.

Material: Stainless steel (AISI 316).

Silicone wind sleeves, guaranteed to stand the test of time. Silicone is a highly flexible synthetic material with an operating temperature range of -100°C to +200°C.

It is UV resistant and will not fade, so it will always look like new.

The air sleeves are removable. The clamping rings and coupling bridge flanges are made of hard synthetic material. The internal color is red (RAL3020). A mosquito net and a stainless steel (AISI 316) cover plate for sealing can be supplied as an option.

Replaces reference JERRY2.

Technical characteristics:

A (in mm): 205.

B (in mm): 75.

C (in mm): 125.

D (in mm): 25.

Free passage area (in cm²): 44.2.

Available in 3 sizes with vertical opening and one with horizontal opening.

Silicone wind sleeves, guaranteed to stand the test of time. Silicone is a highly flexible synthetic material with an operating temperature range of -100°C to +200°C.

It is UV resistant and will not fade, so it will always look like new.

The air sleeves are removable. The clamping rings and coupling bridge flanges are made of hard synthetic material. The internal color is red (RAL3020). A mosquito net and a stainless steel (AISI 316) cover plate for sealing can be supplied as an option. It has a screwed synthetic flange that is easily removable.

Replaces the reference JERRYS.

Technical characteristics:

A (in mm): 192.

B (in mm): 75.

C (in mm): 127.

D (in mm): 11.

Free passage area (in cm²): 44.2.

Available in 3 sizes with vertical opening and one with horizontal opening.

The PFWS system is meticulously designed to ensure a clean and stable water supply every time your boat is out.

Equipped with an adjustable pressure switch, the PFWS allows you to customize the water pressure to suit your specific needs. Ensuring a constant water flow for any onboard activity requiring water. The self-priming pump eliminates the hassle of manually priming the pump, saving you time and effort.

Additionally, the check valve prevents backflow, ensuring the integrity of your water supply and preventing contamination. With a built-in pressure gauge, you can easily monitor water pressure in real time, providing valuable information to optimize system performance. The inlet water filter filters out all impurities, ensuring your water supply remains clean and pure.

Features :

Voltage (V): 12.

Capacity (liters): 19.

Weight (kg): 9.5.

Pipe connection diameter (mm): 19.

Max. pressure (bar): 4.2.

Max. suction height (m): 1.8.

The PFWS system is meticulously designed to ensure a clean and stable water supply every time your boat is out.

Equipped with an adjustable pressure switch, the PFWS allows you to customize the water pressure to suit your specific needs. Ensuring a constant water flow for any onboard activity requiring water. The self-priming pump eliminates the hassle of manually priming the pump, saving you time and effort.

Additionally, the check valve prevents backflow, ensuring the integrity of your water supply and preventing contamination. With a built-in pressure gauge, you can easily monitor water pressure in real time, providing valuable information to optimize system performance. The inlet water filter filters out all impurities, ensuring your water supply remains clean and pure.

Features :

Voltage (V): 24.

Capacity (liters): 19.

Weight (kg): 9.5.

Pipe connection diameter (mm): 19.

Max. pressure (bar): 4.2.

Max. suction height (m): 1.8.

This set consists of a stainless steel ring (AISI 316), a male bridge ring and a fixing key for the DONALD or JERRY hood fan (ref: CHINOOK).

A ring kit is available for each plastic fan size and can be retrofitted to existing models.

This set consists of a stainless steel ring (AISI 316), a male bridge ring and a fixing key for the DONALD or JERRY hood fan (ref: SAMOEN).

A ring kit is available for each plastic fan size and can be retrofitted to existing models.

This set consists of a stainless steel ring (AISI 316), a male bridge ring and a fixing key for the DONALD or JERRY hood fan (ref: TRAMON / LIBEC).

A ring kit is available for each plastic fan size and can be retrofitted to existing models.

Silicone wind sleeves, guaranteed to stand the test of time. Silicone is a highly flexible synthetic material with an operating temperature range of -100°C to +200°C.

It is UV resistant and will not fade, so it will always look like new.

The air sleeves are removable. The clamping rings and coupling bridge flanges are made of hard synthetic material. The internal color is red (RAL3020). A mosquito net and a stainless steel (AISI 316) cover plate for sealing can be supplied as an option.

Replaces the YOGI2 reference.

Technical characteristics:

A (in mm): 295.

B (in mm): 125.

C (in mm): 176.

D (in mm): 25.

Free passage area (in cm²): 122.8.

Available in 3 sizes with vertical opening and one with horizontal opening.

Silicone wind sleeves, guaranteed to stand the test of time. Silicone is a highly flexible synthetic material with an operating temperature range of -100°C to +200°C.

It is UV resistant and will not fade, so it will always look like new.

The air sleeves are removable. The clamping rings and coupling bridge flanges are made of hard synthetic material. The internal color is red (RAL3020). A mosquito net and a stainless steel (AISI 316) cover plate for sealing can be supplied as an option. It has a screwed synthetic flange that is easily removable.

Replaces the YOGIS reference.

Technical characteristics:

A (in mm): 282.

B (in mm): 125.

C (in mm): 179.

D (in mm): 11.

Free passage area (in cm²): 122.2.

Available in 3 sizes with vertical opening and one with horizontal opening.

Tank gauge for drinking water, gasoline, and diesel. Indicates the difference in liquid level every 2.5 cm for maximum accuracy.

Each length of tube contains the maximum number of reed contacts (electronic switches),

instead of the absolute minimum of three (full, half full, empty). For this reason, your tank gauges

will be able to provide maximum accuracy. The contacts are sealed and "liquid-tight".

Technical characteristics:

• Empty 300?

• Full 10?

• For 12 and 24 volts

Features :

Voltage (V): 12/24.

Length (mm): 280.

Tank gauge for drinking water, gasoline, and diesel. Indicates the difference in liquid level every 2.5 cm for maximum accuracy.

Each length of tube contains the maximum number of reed contacts (electronic switches),

instead of the absolute minimum of three (full, half full, empty). For this reason, your tank gauges

will be able to provide maximum accuracy. The contacts are sealed and "liquid-tight".

Technical characteristics:

• Empty 300?

• Full 10?

• For 12 and 24 volts

Features :

Voltage (V): 12/24.

Length (mm): 320.

Tank gauge for drinking water, gasoline, and diesel. Indicates the difference in liquid level every 2.5 cm for maximum accuracy.

Each length of tube contains the maximum number of reed contacts (electronic switches),

instead of the absolute minimum of three (full, half full, empty). For this reason, your tank gauges

will be able to provide maximum accuracy. The contacts are sealed and "liquid-tight".

Technical characteristics:

• Empty 300?

• Full 10?

• For 12 and 24 volts

Features :

Voltage (V): 12/24.

Length (mm): 380.

Tank gauge for drinking water, gasoline, and diesel. Indicates the difference in liquid level every 2.5 cm for maximum accuracy.

Each length of tube contains the maximum number of reed contacts (electronic switches),

instead of the absolute minimum of three (full, half full, empty). For this reason, your tank gauges

will be able to provide maximum accuracy. The contacts are sealed and "liquid-tight".

Technical characteristics:

• Empty 300?

• Full 10?

• For 12 and 24 volts

Features :

Voltage (V): 12/24.

Length (mm): 480.

Tank gauge for drinking water, gasoline, and diesel. Indicates the difference in liquid level every 2.5 cm for maximum accuracy.

Each length of tube contains the maximum number of reed contacts (electronic switches),

instead of the absolute minimum of three (full, half full, empty). For this reason, your tank gauges

will be able to provide maximum accuracy. The contacts are sealed and "liquid-tight".

Technical characteristics:

• Empty 300?

• Full 10?

• For 12 and 24 volts

Features :

Voltage (V): 12/24.

Length (mm): 580.
