Deck panels made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a "dark smoke" color.

These deck hatches come with adjusters that are stylish and easy to use, allowing the cover to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 531 x 401.

Cut-out dimensions C x D (in mm): 457 x 327.

Number of handles: 2.

Shape: Square.

Compatible mosquito net type: HCM4633, HMB4633.

Friction hinges: No.

Deck panels made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a "dark smoke" color.

These deck hatches come with adjusters that are stylish and easy to use, allowing the cover to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 495 x 495.

Cut-out dimensions C x D (in mm): 421 x 421.

Number of handles: 2.

Shape: Square.

Compatible mosquito net type: HCM4242, HMB4242.

Friction hinges: No.

Ventilation hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a "dark smoke" color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 334 x 334.

Cut-out dimensions C x D (in mm): 260 x 260.

Number of handles: 1.

Shape: Square.

Compatible mosquito net type: HCM2626, HMB2626.

Friction hinges: No.

Trapezoidal hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a "dark smoke" color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x BXE (in mm): 636 x 659 x 500.

Cutting dimensions C x DXF (in mm): 557 x 588 x 436

Number of handles: 2.

Shape: Trapezoidal.

Friction hinges: No.

Trapezoidal hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a "dark smoke" color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x BXE (in mm): 543 x 681 x 447.

Cutout dimensions C x DXF (in mm): 464 x 607 x 378

Number of handles: 2.

Shape: Trapezoidal.

Friction hinges: No.

Trapezoidal hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a "dark smoke" color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x BXE (in mm): 513 x 602 x 431.

Cutout dimensions C x DXF (in mm): 434 x 528 x 362.

Number of handles: 2.

Shape: Trapezoidal.

Friction hinges: No.

Ventilation hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a "dark smoke" color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on deck and opened from both the inside and outside. It has a vent position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 421 x 276.

Cut-out dimensions C x D (in mm): 347 x 202.

Number of handles: 1.

Shape: Square.

Friction hinges: No.

Escape hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 680 x 680.

Cut-out dimensions C x D (in mm): 620 x 620.

Cutting radius R (in mm): 55.

Escape hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 680 x 680.

Cut-out dimensions C x D (in mm): 620 x 620.

Cutting radius R (in mm): 32.

Escape hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 560 x 560.

Cut-out dimensions C x D (in mm): 500 x 500.

Cutting radius R (in mm): 55.

Escape hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 560 x 560.

Cut-out dimensions C x D (in mm): 500 x 500.

Cutting radius R (in mm): 32.

Escape hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 470 x 470.

Cut-out dimensions C x D (in mm): 410 x 410.

Cutting radius R (in mm): 55.

Deck hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 560 x 430.

Cut-out dimensions C x D (in mm): 500 x 370.

Cutting radius R (in mm): 55.

Deck hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 560 x 430.

Cut-out dimensions C x D (in mm): 500 x 370.

Cutting radius R (in mm): 32.

Ventilation hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 1.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

Mosquito net type: HCM342.

External dimensions A x B (in mm): 400 x 255.

Cut-out dimensions C x D (in mm): 340 x 195.

Cutting radius R (in mm): 32.

Deck hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 510 x 380.

Cut-out dimensions C x D (in mm): 450 x 320.

Cutting radius R (in mm): 55.
