VETUS rectangular and oval portholes – Marine light and ventilation

Adaptable mounting for PL, PM, PZ, PW and PX portholes.

The new VP000044 knobs are interchangeable with the original PPL knobs.

Ultra-thin portholes - Type PL (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 449 X 264.

Cut-out dimensions C x D (in mm): 429 X 244.

Replacement mosquito net: HOR751.

Ultra-thin portholes - Type PL (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 646 X 191.

Cut-out dimensions C x D (in mm): 626 X 171.

Replacement mosquito net: HOR741.

Ultra-thin portholes - Type PL (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 449 X 191.

Cut-out dimensions C x D (in mm): 429 X 171.

Replacement mosquito net: HOR731.

Ultra-thin portholes - Type PL (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 367 X 191.

Cut-out dimensions C x D (in mm): 347 X 171.

Replacement mosquito net: HOR721.

Ultra-thin portholes - Type PL (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 323 x 176.

Cut-out dimensions C x D (in mm): 303 x 156.

Replacement mosquito net: HOR711

Replacement mosquito net for porthole type PL751.

Replacement mosquito net for porthole type PL741.

Replacement mosquito net for porthole type PL731.

Replacement mosquito net for porthole type PL721.

Replacement mosquito net for porthole type PL711.

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 399 x 199.

Cut-out dimensions C x D (in mm): 375 x 175.

Cutting radius R (in mm): 87.

Replacement mosquito net: HOR16.

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 390 x 220.

Cut-out dimensions C x D (in mm): 366 x 196.

Cutting radius R (in mm): 98.

Replacement mosquito net: HOR15.

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 344 x 198.

Cut-out dimensions C x D (in mm): 230 x 174.

Cutting radius R (in mm): 87.

Replacement mosquito net: HOR13.

Hublot ultra minces - Type PM (AI)

Les hublots de la série PL sont si affleurants qu'ils ressemblent à du verre fritté et conviennent pour être installés dans

une variété de matériaux.

Malgré leur faible épaisseur, ils sont toujours homologués CE pour la zone de localisation AI, ce qui signifie qu'ils sont utilisables pour tous les domaines répertoriés dans la norme ISO ! Un bord en aluminium très plat combiné au mécanisme de serrage assure un hublot à profil très bas même lorsqu'il est monté dans le verre lui-même. Ils sont également équipés des nouveaux boutons ergonomiques.

Ces hublots ultra minces peuvent accepter des épaisseurs de panneaux allant de 2 à 20 mm. L'intérieur du profil de serrage peut être fini avec la garniture fournie. Tous

les hublots PL sont en aluminium noir satiné à la mode avec de l'acrylique teinté « fumée noire » de 10 mm d'épaisseur pour un look haut de gamme.

Caractéristiques :

Dimensions extérieures A x B (en mm) : 362 x 146.

Dimensions de découpe C x D (en mm) : 338 x 122.

Radius découpe R (en mm) : 61.

Moustiquaire de remplacement : HOR14.

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 294 x 172.

Cut-out dimensions C x D (in mm): 270 x 148.

Cutting radius R (in mm): 74.

Replacement mosquito net: HOR12.

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 244 x 146.

Cut-out dimensions C x D (in mm): 220 x 122.

Cutting radius R (in mm): 61.

Replacement mosquito net: HOR11.

Replacement mosquito net for porthole type PM161 and PM163.

Replacement mosquito net for porthole type PM151 and PM153.

Replacement mosquito net for porthole type PM141 and PM143.

Replacement mosquito net for porthole type PM131 and PM133.

Replacement mosquito net for porthole type PM121 and PM123.

Replacement mosquito net for porthole type PM111 and PM113.

Stainless steel portholes - Type PMS (AI)

VETUS offers a range of portholes made of stainless steel (AISI 316) in categories AI and AII.

They come with a stainless steel (AISI 316) inner frame, 8mm "smoked" acrylic glazing and a mosquito net on anodized aluminum frame.

These portholes are suitable for a structure thickness of 3 to 18mm.

Screws for different wall thicknesses can be ordered separately.

Features :

External dimensions A x B (in mm): 346 x 199.

Cut-out dimensions C x D (in mm): 322 x 177.

Replacement mosquito net: HOR23S.
