complete SUZUKI trim cylinder cap.

sold with its three sealing gaskets.

2-wire trim motor for the following Yamaha 75 to 100HP 4-stroke outboards:

- 75 and 80HP 4-stroke from 1999 to 2004

- 90 and 100HP 4-stroke from 1999 to 2004

4 screw fixing, reassembly kit included.

Johnson - Evinrude outboard trim motor types Fitch Ram FFI from 75 to 300HP.

Fixing with 4 screws.

Reassembly gaskets included.

Mercruiser trim pump oil reservoir with mounting screw.

Complete gasket kit for rebuilding Johnson - Evinrude trim cylinders.

Complete gasket kit for Mercury trim cylinder on Verado (L6), DFI and EFI type engines.

Hydraulic hose for Volvo Penta DPH base:

Length between the head of the fixing nut on the plate and the head of the fixing nut on the jack + or - 29cm

DPH-A, DPH-C, DPH-D, DPH-D1

DPR-A, DPR-B, DPR-C, DPR-DM

TSK DPH-B

Material with the protective black coating equivalent to Volvo OEM.

Hydraulic hose for Volvo Penta DPH base

Length between the head of the fixing nut on the plate and the head of the fixing nut on the jack + or - 26cm

DPH-A, DPH-C, DPH-D, DPH-D1

DPR-A, DPR-B, DPR-C, DPR-DM

TSK DPH-B

Material with the protective black coating equivalent to Volvo OEM.

Set of 4 hydraulic hoses for Volvo DPH base.

Trim sensor to provide the position of the Volvo Penta SX-A and DPS-B drive.

Sensors with 3 wires with x-drive:

- Black

- Black - brown

- Green - red

Trim sensor for Mercruiser engine in DTS.

Blue - white - red colored threads.

Kit including a DTS 3-wire trim sensor and a plastic cover.

Trim sensor for Mercury outboard motors with digital instrumentation with LEDs.

Vérin tribord complet pour embase Mercruiser Alpha One génération 2.

Seal kit for DPH 21745117 steering cylinder.

Seal kit for steering cylinder with or without electric indicator type DPH 22452003.

Complete Mercury trim cylinder cap.

Sold with its three sealing gaskets.

2-wire trim motor for Suzuki DT40 from 1994 to 1998.

Flat training.

2-wire trim motor for the following Yamaha 40 to 60HP outboards:

- 50HP 4-stroke from 2001 to 2004

- 60HP 4-stroke from 2002 to 2004

- 40HP 2-stroke from 2001 to 2006

- 50HP 2-stroke from 2003 to 2009

3 fixing screws, reassembly kit included.

2-wire trim motor for Johnson - Evinrude outboards 25 to 50HP after 1992.

As well as the following Honda engines from 1992 to 2002:

- BF35

- BF40

- BF45

- BF50

Mounting with 4 fixing screws.

Female drive axle.

OMC base lifting motor of mechanical types.

Connection for hydraulic tapping on ARC6227 trim pump.

Complete original Mercury OEM trim motor with 2-wire assembly to replace the older Mercury generations from 1996 and later:

- 135 to 200CV 2.5L 2-stroke

- 200 to 300CV 3.0L 2-stroke

- 135, 150, 175, 200 HP 4-Stroke VERADO L4

This set can also replace the 3-wire generations with the use of the conversion kit reference WH476.

Kit to convert a 3-wire set to a 2-wire set with the use of this adapter.

The engine generations concerned are the following between 1985 and 1995 135 to 225hp 2-stroke.

The 00052A trim bar anode is included in the kit.

Trim complet en remplacement des trims mono bras Mercury disposant d'un raccordement 2 fils suivants :

- 75, 90 3 Cyl 2Temps

- 100, 115, 125 4Cyl 2Temps

- 75, 90, 115, 125 DFI 1.5L 3Cyl Opyimax

- 75, 90 4Temps Carbu

- 75, 80, 90, 100, 115 EFI 4Temps

Pour la conversion d'un ancien système 3 fils merci de commande en plus la référence WH476.
