Trim cylinders for marine engines and lower units

Seal kit for the repair of a base cylinder:

- DPH-A

- DPH-B

- DPH-C

- DPH-D

- DPH-E

- DPR-A

- DPR-B

- DPR-C

OEM References: 3888301 - 3887960 - 21840806 - 2180807

Seal kit for repairing a Volvo Penta cylinder type 872612 or 3860881 with round ends.

Kit for one jack.

Cylinder cap for Volvo base types:

- SX

- SX-M

- SX-S

- DP-SM

Mounting intended for cylinders of type 3857470.

Remember to add the reassembly seal kit 22173.

Kit de joints pour un vérin d'embase Volvo - OMC de types :

- SX

- SX-M

- DP-SM

- OMC COBRA

- OMC KING COBRA

Kit universel pour vérin toutes génération disposant aussi bien des flexibles sur l'arrière que sur l'avant.

Le joint torique étant plus facile à installer que la bague rouge.

Cylinder cap for the following Volvo bases:

AQ290, AQ290DP

SP-A, SP-A1, SP-A2, SP-E

DP-A, DP-A1, DP-A2, DP-B, DP-B1, DP-C1

DP-E, DP-G

DPX-A, DPX-S

Mounting for cylinders of types: 872612, 3860881

Thread diameter: 39.4 mm

Seal kit for repairing old Volvo 853439 cylinders with the U-shaped end piece.

Kit for one jack.

For the repair kit for cylinders with the round tip, please refer to reference 22165.

Cylinder rod for Volvo Penta outdrives:

DP-SM, SX, SX-M, SX-S

TSK SX-M, TSK SX-MACLT, TSK SX-MBAC, TSK SX-MDA

TSK SX-MDB, TSK SX-MDC, TSK SX-MHP, TSK SX-MLT

Cylinder seal kit for Mercruiser Alpha one Generation 1 and 2

as well as Bravo 1 - 2 and 3

Cylinder cap for the following Volvo bases:

AQ290, AQ290DP

SP-A, SP-A1, SP-A2, SP-E

DP-A, DP-A1, DP-A2, DP-B, DP-B1, DP-C1

DP-E, DP-G

DPX-A, DPX-S

Mounting for cylinders of types: 872612, 3860881

Thread diameter: 39.8 mm

Complete port cylinder for Mercruiser Alpha One generation 2 base.

Kit joints pour vérin de direction assistée sur embases Volvo DPR DPH suivants : 21745119

Port trim cylinder for Volvo Penta drive types:

- DPS-A

- SX-A

Complete starboard cylinder for Mercruiser Bravo base.

Cylinder shaft for Volvo Penta base types:

- 290

- SP

- DP

- DPE

- DPX

- DP-G

- DP-S

Mounting on jacks 3860881.

Axle length 194.50 mm.

Complete seal kit for a Volvo Penta sterndrive cylinder type SX-A and DPS-A.

Mounting for the following cylinders:

- 3889954

- 3889955

- 3889956

- 3889957

- 3889958

- 3889959

Starboard trim cylinder for Volvo Penta drive types:

- DPS-A

- SX-A

Complete trim cylinder kit for VOLVO - OMC base types: SX - SX-M - DP-SM.

Kit including:

2 pcs jacks

All trim hoses.

The necessary mounting materials, namely covers, nuts, washers.

Complete cylinder kit including the 2 cylinders, the hydraulic hoses and all the necessary mounting equipment for replacing the old generation 853439 cylinders as well as the 872612.

The following hoses are also included:

- 854696

- 854697

- 872596

- 872595

Mounting on DP - SP base.

Complete port cylinder for Mercruiser Bravo base.

Cylinder cap for Volvo Penta outdrives of types:

DPH-A

DPH-B

DPH-C

DPH-D

DPH-E

DPR-A

DPR-B

DPR-C

Complete starboard cylinder for Mercruiser Alpha One generation 2 base.

Cylinder shaft for Volvo Penta base types DPH - DPR with cylinders:

- 3888301

- 3887960

- 21840806

Material not available from Volvo Penta.

Cylinder shaft for Volvo Penta sterndrive types SX-A and DPS-A with cylinders:

- 22187385

- 22187386

- 22187388

- 22187391

- 22187387

- 22187289

Material not available from Volvo Penta.

Complete Mercury trim cylinder cap.

Sold with its three sealing gaskets.

Cylinder seal kit for Mercruiser TRS base with internal hydraulic hose assembly.

Short type hydraulic hoses on the rear of the cylinder.
