Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 1150 kgf

A (in mm): 180

B (in mm): 142

Ø (in mm): 70

C (in mm): 140 x 118

D (in mm): 82

E (in mm): 4 x Ø8.50

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 1150 kgf

A (in mm): 160

B (in mm): 110

Ø (in mm): 60

D (in mm): 60

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 1150 kgf

A (in mm): 160

B (in mm): 120

Ø (in mm): 60

C (in mm): 122 x 97

D (in mm): 70

E (in mm): 4 x Ø6.5

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 130

B (in mm): 90

Ø (in mm): 50

D (in mm): 47

Mooring bitt in stainless steel (AISI 316).

To bolt

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 1360

B (in mm): 95

Ø (in mm): 50

D (in mm): 52

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 130

B (in mm): 95

Ø (in mm): 50

C (in mm): 92 x9 2

D (in mm): 52

E (in mm): 4 x Ø6.5

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 120

B (in mm): 80

Ø (in mm): 40

D (in mm): 42

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 120

B (in mm): 90

Ø (in mm): 40

C (in mm): 80 x 65

D (in mm): 52

E (in mm): 4 x Ø6.5

Compact, audible electric horns. Horn made of chrome-plated ABS and stainless steel. Supplied with relay. Also available in 12V.

Features :

Number: 1

Tone: Low

Freq. (in Hz): 420

Volume: 115 dB

Length (in mm): 97

Height (in mm): 114

Width (in mm): 95

Compact, audible electric horns. Horn made of chrome-plated ABS and stainless steel. Supplied with relay. Also available in 12V.

Features :

Number: 1

Tone: High

Freq. (in Hz): 480

Volume: 115 dB

Length (in mm): 97

Height (in mm): 114

Width (in mm): 95

Compact, audible electric horns. Horn made of chrome-plated ABS and stainless steel. Supplied with relay. Also available in 12V.

Features :

Number: 2

Tone: High + Low

Volume: 115 dB

Length (in mm): 195

Height (in mm): 114

Width (in mm): 95

Compact, audible electric horns. Horn made of chrome-plated ABS and stainless steel. Supplied with relay. Also available in 24V.

Features :

Number: 1

Tone: Low

Freq. (in Hz): 420

Volume: 115 dB

Length (in mm): 97

Height (in mm): 114

Width (in mm): 95

Compact, audible electric horns. Horn made of chrome-plated ABS and stainless steel. Supplied with relay. Also available in 24V.

Features :

Number: 1

Tone: High

Freq. (in Hz): 480

Volume: 115 dB

Length (in mm): 97

Height (in mm): 114

Width (in mm): 95

Compact, audible electric horns. Horn made of chrome-plated ABS and stainless steel. Supplied with relay. Also available in 24V.

Features :

Number: 2

Tone: High + Low

Volume: 115 dB

Length (in mm): 195

Height (in mm): 114

Width (in mm): 95

Flush electric warning lights.

The housing is made of plastic and the membrane is made of stainless steel (AISI 304).

Available in 12V. White, black and chrome ABS cover included.

Features :

Volume: 110 dB

Cover length (in mm): 128

Depth (in mm): 95

Cover width (in mm): 62

Telescopic ladder on stainless steel platform (AISI 316).

Available with 3 or 4 steps. The steps are covered with black synthetic anti-slip material.

Features :

Number of steps: 4

Unfolded length (in mm): 1165

Folded length (in mm): 405

Width between tube centers: 256

Tube Ø (in mm): 19/25/32/38

Weight (in kg): 5.10

Max. load (in mm): 300

Deluxe folding ladder with deck mounting.

Robust and reinforced model in stainless steel (AISI316) with L-shaped joint and available in 4 steps.

The steps are covered with black synthetic anti-slip.

The length is 1140 mm below deck when fully unfolded. Also has handrails for easy re-boarding.

Features :

Number of steps: 4

Unfolded length (in mm): 1600

Folded length (in mm): 480

Width between tube centers: 380

Tube Ø (in mm): 19/25/32/38

Weight (in kg): 8.50

Max. load (in mm): 300

Integrated telescopic ladder in stainless steel (AISI 316).

Available with 3 or 4 steps. The steps are covered with black synthetic anti-slip material.

Features :

Number of steps: 4

Unfolded length (in mm): 1160

Folded length (in mm): 0

Width between tube centers: 256

Tube Ø (in mm): 19/25/32/38

Weight (in kg): 8.00

Max. load (in mm): 300

Telescopic ladder in stainless steel (AISI 316).

Available with 3 or 4 steps and in 2 different widths. The steps are covered with black synthetic anti-slip material.

Features :

Number of steps: 4

Unfolded length (in mm): 1160

Folded length (in mm): 415

Width between tube centers: 355

Tube Ø (in mm): 19/25/32/38

Weight (in kg): 4.00

Max. load (in mm): 300

Telescopic ladder in stainless steel (AISI 316).

Available with 3 or 4 steps and in 2 different widths. The steps are covered with black synthetic anti-slip material.

Features :

Number of steps: 4

Unfolded length (in mm): 1165

Folded length (in mm): 405

Width between tube centers: 256

Tube Ø (in mm): 19/25/32/38

Weight (in kg): 3.60

Max. load (in mm): 300

Telescopic ladder on stainless steel platform (AISI 316).

Available with 3 or 4 steps. The steps are covered with black synthetic anti-slip material.

Features :

Number of steps: 3

Unfolded length (in mm): 875

Folded length (in mm): 370

Width between tube centers: 256

Tube Ø (in mm): 19/25/32

Weight (in kg): 3.60

Max. load (in mm): 300

Telescopic ladder in stainless steel (AISI 316).

Available with 3 or 4 steps and in 2 different widths. The steps are covered with black synthetic anti-slip material.

Features :

Number of steps: 3

Unfolded length (in mm): 895

Folded length (in mm): 375

Width between tube centers: 355

Tube Ø (in mm): 19/25/32

Weight (in kg): 2.90

Max. load (in mm): 300

Telescopic ladder in stainless steel (AISI 316).

Available with 3 or 4 steps and in 2 different widths. The steps are covered with black synthetic anti-slip material.

Features :

Number of steps: 3

Unfolded length (in mm): 880

Folded length (in mm): 375

Width between tube centers: 256

Tube Ø (in mm): 19/25/32

Weight (in kg): 2.70

Max. load (in mm): 300
