V-Quipment – VETUS Deck Hardware and Boat Accessories - Page 16

Underdeck fixing with a threaded finish on the underside so that no fixing is visible.

Made of stainless steel (AISI 316) with a high-gloss polished finish.

Features :

Permissible load (with safety margin): 900 kgf

A (in mm): 195

B (in mm): 60

C x C (in mm): 120.5 x 35

D (in mm): 69

E (in mm): 2 x M10

Underdeck fixing with a threaded finish on the underside so no fixings are visible.

Made of stainless steel (AISI 316) with a high-gloss polished finish.

Features :

Permissible load (with safety margin): 575 kgf

A (in mm): 140

B (in mm): 50

C x C (in mm) 89.5 x 30:

D (in mm): 47

E (in mm): 2 x M8

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 2620 kgf

A (in mm): 255

B (in mm): 160

Ø (in mm): 90

D (in mm): 82

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 2620 kgf

A (in mm): 255

B (in mm): 195

Ø (in mm): 90

C (in mm): 165 x 135

D (in mm): 120

E (in mm): 4 x Ø12.7

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 1800 kgf

A (in mm): 200

B (in mm): 150

Ø (in mm): 80

D (in mm): 78

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 1800 kgf

A (in mm): 200

B (in mm): 172

Ø (in mm): 80

C (in mm): 153 x 122

D (in mm): 100

E (in mm): 4 x Ø10.5

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 1150 kgf

A (in mm): 180

B (in mm): 130

Ø (in mm): 70

D (in mm): 70

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 1150 kgf

A (in mm): 180

B (in mm): 142

Ø (in mm): 70

C (in mm): 140 x 118

D (in mm): 82

E (in mm): 4 x Ø8.50

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 1150 kgf

A (in mm): 160

B (in mm): 110

Ø (in mm): 60

D (in mm): 60

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 1150 kgf

A (in mm): 160

B (in mm): 120

Ø (in mm): 60

C (in mm): 122 x 97

D (in mm): 70

E (in mm): 4 x Ø6.5

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 130

B (in mm): 90

Ø (in mm): 50

D (in mm): 47

Mooring bitt in stainless steel (AISI 316).

To bolt

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 1360

B (in mm): 95

Ø (in mm): 50

D (in mm): 52

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 130

B (in mm): 95

Ø (in mm): 50

C (in mm): 92 x9 2

D (in mm): 52

E (in mm): 4 x Ø6.5

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 120

B (in mm): 80

Ø (in mm): 40

D (in mm): 42

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 620 kgf

A (in mm): 120

B (in mm): 90

Ø (in mm): 40

C (in mm): 80 x 65

D (in mm): 52

E (in mm): 4 x Ø6.5

"Ferry Bench" comfort bench.

The "Ferry Bench" is a comfortable luxury bench (2 seats) with a folding backrest.

Its hinged plates are made of anodized aluminum. It is covered in water- and UV-resistant, maintenance-free faux leather, ideal for marine use.

Attaches with 2 feet with or without slide. Supplied without pedestal.

Colors: White gray with blue stitching.

Also available in colors: Blue with gray white stitching.

Features :

D1 (in mm): 570.

D2 (in mm): 375.

H1 (in mm): 460.

H2 (in mm): 380.

W1 (in mm): 900.

W2 (in mm): 900.

Template: 2xR./ 2xS

Weight (in kg): 15.00.

"Ferry Bench" comfort bench.

The "Ferry Bench" is a comfortable luxury bench (2 seats) with a folding backrest.

Its hinged plates are made of anodized aluminum. It is covered in water- and UV-resistant, maintenance-free faux leather, ideal for marine use.

Attaches with 2 feet with or without slide. Supplied without pedestal.

Color: Blue with gray white stitching.

Also available in: White gray with blue stitching.

Features :

D1 (in mm): 570.

D2 (in mm): 375.

H1 (in mm): 460.

H2 (in mm): 380.

W1 (in mm): 900.

W2 (in mm): 900.

Template: 2xR./ 2xS

Weight (in kg): 15.00.

Luxury "First Class" bench seat.

The "First Class" is a comfortable luxury bench seat (2 seats) with a folding backrest.

Its hinged plates are made of anodized aluminum. It is covered in water- and UV-resistant, maintenance-free faux leather, ideal for marine use.

Attaches with 2 feet. Supplied without pedestal.

Colors: White gray with blue stitching.

Also available in colors: Blue with gray white stitching.

Features :

D1 (in mm): 480.

D2 (in mm): 350.

H1 (in mm): 450.

H2 (in mm): 360.

W1 (in mm): 900.

W2 (in mm): 900.

Template: 2xR.

Weight (in kg): 13.00.

Luxury "First Class" bench seat.

The "First Class" is a comfortable luxury bench seat (2 seats) with a folding backrest.

Its hinged plates are made of anodized aluminum. It is covered in water- and UV-resistant, maintenance-free faux leather, ideal for marine use.

Attaches with 2 feet. Supplied without pedestal.

Color: Blue with gray white stitching.

Also available in: White gray with blue stitching.

Features :

D1 (in mm): 480.

D2 (in mm): 350.

H1 (in mm): 450.

H2 (in mm): 360.

W1 (in mm): 900.

W2 (in mm): 900.

Template: 2xR.

Weight (in kg): 13.00.

"Ferry" comfort seat.

The "Ferry" is a comfortable seat with a reversible folding backrest.

Its hinged plates are made of anodized aluminum. It is covered in water- and UV-resistant, maintenance-free faux leather, ideal for marine use.

Fits all pedestals with slide. Comes without pedestal.

Colors: White gray with blue stitching.

Also available in colors: Blue with gray white stitching.

Use the CCDS or CCSB seat cover to keep the seat clean.

Features :

D1 (in mm): 570.

D2 (in mm): 375.

H1 (in mm): 460.

H2 (in mm): 380.

W1 (in mm): 420.

W2 (in mm): 420.

ØT (in mm): 706.

Template: R/S.

Weight (in kg): 6.00.

Pilot-style comfort seat.

The "Pilot" is a comfortable sports-style seat with a folding front section for driving in a standing or leaning position.

Fits all pedestals with slide. Comes without pedestal.

Use the CCDS or CCSB seat cover to keep the seat clean.

Colors: Gray white with black.

Also available in colors: Cognac, White Grey, Black and without coating.

Features :

D1 (in mm): 670.

D2 (in mm): 475.

H1 (in mm): 600.

H2 (in mm): 510.

W1 (in mm): 500.

W2 (in mm): 403.

ØT (in mm): 720.

Template: R.

Weight (in kg): 8.70.

"Ferry" comfort seat.

The "Ferry" is a comfortable seat with a reversible folding backrest.

Its hinged plates are made of anodized aluminum. It is covered in water- and UV-resistant, maintenance-free faux leather, ideal for marine use.

Fits all pedestals with slide. Comes without pedestal.

Color: Blue with gray white stitching.

Also available in: White gray with blue stitching.

Use the CCDS or CCSB seat cover to keep the seat clean.

Features :

D1 (in mm): 570.

D2 (in mm): 375.

H1 (in mm): 460.

H2 (in mm): 380.

W1 (in mm): 420.

W2 (in mm): 420.

ØT (in mm): 706.

Template: R/S.

Weight (in kg): 6.00.

Pilot-style comfort seat.

The "Pilot" is a comfortable sports-style seat with a folding front section for driving in a standing or leaning position.

Fits all pedestals with slide. Comes without pedestal.

Use the CCDS or CCSB seat cover to keep the seat clean.

Colors: White gray.

Also available in colors: Cognac, Black, White Gray and without coating.

Features :

D1 (in mm): 670.

D2 (in mm): 475.

H1 (in mm): 600.

H2 (in mm): 510.

W1 (in mm): 500.

W2 (in mm): 403.

ØT (in mm): 720.

Template: R.

Weight (in kg): 8.70.

"Pilot" type comfort seat without upholstery.

The "Pilot" is a comfortable sports-style seat with a folding front section for driving in a standing or leaning position.

Fits all pedestals with slide. Comes without pedestal.

Use the CCDS or CCSB seat cover to keep the seat clean.

Color: uncoated.

Also available in colors: Cognac, White gray, White gray and Black.

Features :

D1 (in mm): 670.

D2 (in mm): 475.

H1 (in mm): 600.

H2 (in mm): 510.

W1 (in mm): 500.

W2 (in mm): 403.

ØT (in mm): 720.
