V-Quipment – VETUS Deck Hardware and Boat Accessories

Stainless steel deck filler (AISI 316)

The stainless steel deck filler with mirror-polished stainless steel waterproof cover.

Available for:

- Water

- Essence

- Diesel

- Black water (WC)

Technical characteristics:

Cap (Q) diameter: 86.5 mm

Type: Key

Liquid: Diesel

Pipe (U) diameter: 38 mm

Cutout (B) diameter: 51 mm

Length (H): 82.5 mm

Handrail tube in stainless steel (AISI 316).

Available in Ø 20 and 25mm.

The tube is available by the meter. Fasteners must be ordered separately.

Features :

Wall thickness (in mm): 25

Max tube length (in mm): 1.50

Tube Ø (in mm): 6000

Handrail tube in stainless steel (AISI 316).

Available in Ø 20 and 25mm.

The tube is available by the meter. Fasteners must be ordered separately.

Features :

Wall thickness (in mm): 20

Max tube length (in mm): 1.50

Tube Ø (in mm): 6000

Underdeck fixing with a threaded finish on the underside so that no fixing is visible.

4 holes in a rectangle according to dimensions D. The holes are countersunk at 90º.

Made of stainless steel (AISI 316) with a high-gloss polished finish.

Features :

Permissible load (with safety margin): 2620 kgf

A (in mm): 300

B (in mm): 85

C x C (in mm) 200 x 85:

D (in mm): 130 x 55

E (in mm): 4 x Ø12.5

Underdeck fixing with a threaded finish on the underside so that no fixing is visible.

Made of stainless steel (AISI 316) with a high-gloss polished finish.

Features :

Permissible load (with safety margin): 2470 kgf

A (in mm): 300

B (in mm): 85

C x C (in mm) 200 x 85:

D (in mm): 83

E (in mm): 2 x M16

Underdeck fixing with a threaded finish on the underside so that no fixing is visible.

Made of stainless steel (AISI 316) with a high-gloss polished finish.

Features :

Permissible load (with safety margin): 2470 kgf

A (in mm): 300

B (in mm): 85

C x C (in mm) 160 x 50:

D (in mm): 83

E (in mm): 2 x M16

Underdeck fixing with a threaded finish on the underside so that no fixing is visible.

Made of stainless steel (AISI 316) with a high-gloss polished finish.

Features :

Permissible load (with safety margin): 1310 kgf

A (in mm): 255

B (in mm): 75

C x C (in mm) 150 x 40:

D (in mm): 83

E (in mm): 2 x M12

Underdeck fixing with a threaded finish on the underside so that no fixing is visible.

Made of stainless steel (AISI 316) with a high-gloss polished finish.

Features :

Permissible load (with safety margin): 900 kgf

A (in mm): 195

B (in mm): 60

C x C (in mm): 120.5 x 35

D (in mm): 69

E (in mm): 2 x M10

Underdeck fixing with a threaded finish on the underside so no fixings are visible.

Made of stainless steel (AISI 316) with a high-gloss polished finish.

Features :

Permissible load (with safety margin): 575 kgf

A (in mm): 140

B (in mm): 50

C x C (in mm) 89.5 x 30:

D (in mm): 47

E (in mm): 2 x M8

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 2620 kgf

A (in mm): 255

B (in mm): 160

Ø (in mm): 90

D (in mm): 82

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 2620 kgf

A (in mm): 255

B (in mm): 195

Ø (in mm): 90

C (in mm): 165 x 135

D (in mm): 120

E (in mm): 4 x Ø12.7

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 1800 kgf

A (in mm): 200

B (in mm): 150

Ø (in mm): 80

D (in mm): 78

Mooring bitt in stainless steel (AISI 316).

Features :

Permissible load (with safety margin): 1800 kgf

A (in mm): 200

B (in mm): 172

Ø (in mm): 80

C (in mm): 153 x 122

D (in mm): 100

E (in mm): 4 x Ø10.5

Mooring bitt in stainless steel (AISI 316).

Intended for direct mounting on the deck.

Features :

Permissible load (with safety margin): 1150 kgf

A (in mm): 180

B (in mm): 130

Ø (in mm): 70

D (in mm): 70
