CAPOT - TRAPPE TYPE ALTUS

Escape hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions: Ø 592.

Cut-out dimensions: Ø 518.

Number of handles: 2.

Mosquito net type: HCMR520.

Shape: Round.

Friction hinges: No.

Deck panels made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These deck hatches come with adjusters that are stylish and easy to use, allowing the cover to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions: Ø 491.

Cut-out dimensions: Ø 417.

Number of handles: 2.

Shape: Round.

Compatible mosquito net type: HCM420.

Friction hinges: No.

Escape hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 592 x 524

Cut-out dimensions C x D (in mm): 518 x 450.

Number of handles: 2.

Mosquito net type: HCMD520.

Shape: Oval.

Friction hinges: No.

Escape hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 701 x 701.

Cut-out dimensions C x D (in mm): 627 x 627.

Number of handles: 2.

Mosquito net type: HCM6363.

Shape: Square.

Friction hinges: No.

Escape hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 581 x 581.

Cut-out dimensions C x D (in mm): 507 x 507.

Number of handles: 2.

Mosquito net type: HCM5151.

Shape: Square.

Friction hinges: No.

Deck panels made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These deck hatches come with adjusters that are stylish and easy to use, allowing the cover to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 581 x 451.

Cut-out dimensions C x D (in mm): 507 x 377.

Number of handles: 2.

Shape: Square.

Compatible mosquito net type: HCM5038, HMB5038.

Friction hinges: No.
