RC8-6 COMBINED VERTICAL CHAIN/ROPE WINDLASS - 24V CW - 600W 165TDC - 6MM CHAIN
The RC8-6 series in stainless steel (AISI 316) incorporates a chrome-plated bronze tray, designed to effortlessly retrieve and deploy 6mm/7mm chain spliced onto 12mm 8-strand (braided) cable.
The ingenious Wave Designâ„¢ chain/rope system (chainwheel) is capable of accommodating a wide range of chain pitch differences within the specified chain size diameters. A sleek, low-profile version and a stainless steel (AISI 316) splined capstan drum version are available. The heavy-duty stainless steel (AISI 316) pressure arm is designed to effectively help grip the cable/chain splice, giving the RC8 series an unmatched level of performance. In combination with a heavy-duty, large-diameter stainless steel (AISI 316) pre-loaded spring, the pressure arm always exerts maximum control pressure. Works equally effectively with chain-driven bicycles. The huge through deck hawse chute ensures easy entry and exit of the cable/chain in and out of the anchor locker. The sealed oil bath and marine grade hard anodized alloy gearbox provide maximum efficiency with a screw and worm wheel.
Simple two-piece installation saves time and money and allows for easy retrofitting without windlass disassembly. Unique spacer tube design allows installation on virtually any deck thickness and multiple mounting positions. Self-aligning gearbox ensures optimal gearbox and motor location in virtually any installation situation. Complete topworks disassembly is possible using only the supplied handle and an Allen key. A "free fall" manual override, using the emergency clutch crank/handle, is also provided.
Features :
Rope (in mm): 12.
Rope/Chain: Rope / chain.
Drum: Yes.
Motor (in W): 600.
Weight (in kg): 12.50.
Maximum traction/lift (in kg): 350.
Short chain link (in mm): 6-7.
Chain (in mm): 6-7.
Vertical/Horizontal: Vertical.
Voltage (in V): 24.
