Solid plate without water tap for Chrysler manifold.

Stainless steel exhaust elbow for the following Northern Lights generator sets:

M16C

M20CL / M20CR / M20CR2 / M20CRW2

M753W2 / NL753W2 / M753G / M773LW2 / M773LW3 / NL773LW3

M843NW2 / M843NW3 / NL843NW2 / NL843NW3

L844D / M844K / M844LK / M844K2 / M844LK2 / M844LW2 / M844W2 / NL844K / NL844LK / NL844K2 / NL844LK2 / NL844LW2 / NL844W2

Stainless steel exhaust elbow for Volvo Penta D12 series engines - TAMD164 - TAMD165.

Kit including:

- 2X 863442 fixing flange

- Elbow joint 863353

- Water connection 813644

- Cap 2x 914392

- Cap 981749

90° stainless steel exhaust elbow riser for Volvo Penta engine:

- D5A-B, D5A-T, D5A-TA

- D7A-B TA, D7A-T, D7A-TA, D7C-B TA, D7C-TA

- TAMD63L-A, TAMD63P-A

- TAMD71B

- TAMD72

- TAMD73P-A, TAMD73WJ-A

- TAMD74A, TAMD74A-A, TAMD74A-B, TAMD74C-A, TAMD74C-B, TAMD74L-A, TAMD74L-B, TAMD74P-A, TAMD74P-B

- TAMD75P-A

Remember to add thermal protection with reference MAT7.

Coude d'échappement inox pour moteurs Detroit Diesel de types :

6V71

6V92

8.2T

8.2TI

8V71

Exhaust elbow for Yanmar 6LY series engine.

Featuring a Ø 128mm exhaust outlet and a Ø 38mm water inlet.

Stainless steel exhaust elbow for Yanmar 1 - 2 and 3 cylinder engines.

Link fitting 104214-13580 included with the elbow.

Water tap connection not included under reference 104407-44480 in diameter 17.5mm.

Material also available in CAST IRON under the reference YM123000.

The outlet is designed for a 53mm diameter hose but also has a thread to adapt the outlet according to your installation.

Port exhaust elbow for 5.7 Indmar engine catalyzed after 2011.

Coude d'échappement tribord pour moteur 5.7 Indmar catalysé après 2011.

Complete stainless steel exhaust manifold kit for the following Yanmar QM series engines:

- 2QM15

- 2QM20

- 3QM30

- 3QM30H

Replacement/conversion kit for optional raised mounting including:

- The collector plate integrating the connection allowing the connection nipple to be received (conversion).

- The connecting nipple raised to 3 inches.

- The collector reassembly gasket.

The YM123000 or YM123000I exhaust elbow is not included.

Remember to add it.

Equipment not compatible with Yanmar series: GM, HM, JH, YM

Stainless steel exhaust elbow for replacement of the Yanmar 6LY-UTE assembly with mounting screws.

Kit including the necessary assembly materials, namely:

- hose clamp

- Mounting gasket

- adapter flange

Exhaust diameter 127mm.

Spacer positioned between the elbow and the exhaust manifold of OMC 4-cylinder 2.5L and 6-cylinder in-line 165hp engines to adapt the water passages.

Exhaust outlet acting as a reducer for mounting on OMC 4-cylinder round elbow type OMC20980536.

Outlet diameter 60mm, 3 screw fixing.

Exhaust elbow for Mercruiser engine.

Mounting hardware included.

Thermal insulation for Yanmar exhaust elbow YM119175-13301.

Exhaust elbow for Mercruiser 3.7 liter 4 cylinder type 470 engine.

Stainless steel elbow for Yanmar 4LH series engine.

Stainless steel exhaust elbow for Perkins 4.236 M90 engine.

Reassembly gasket included.

Stainless steel exhaust elbow for Yanmar 4LH-HTE and 4LH-TE engines.

Reassembly gasket 119171-13510 included.

Exhaust elbow for Mercruiser diesel engines based on VM in shaft assembly with a 65° inclination.

Coude d'échappement en inox pour moteurs Nothern Lights de types :

M30C / M30CW / M33C / M33CW / M38CR2 / M864K / M864W / M864W3 / L944D / M944T / M944W / NL944D2 / ML944T2 / L984 / M984K / M984W / ML984
