Silicone wind sleeves, guaranteed to stand the test of time. Silicone is a highly flexible synthetic material with an operating temperature range of -100°C to +200°C.

It is UV resistant and will not fade, so it will always look like new.

The air sleeves are removable. The clamping rings and coupling bridge flanges are made of hard synthetic material. The internal color is red (RAL3020). A mosquito net and a stainless steel (AISI 316) cover plate for sealing can be supplied as an option.

Replaces reference TOM2.

Technical characteristics:

A (in mm): 244.

B (in mm): 100.

C (in mm): 152.

D (in mm): 25.

Free passage area (in cm²): 78.6.

Available in 3 sizes with vertical opening and one with horizontal opening.

White interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 296.

B (in mm): 125.

C (in mm): 181.

D (in mm): 22.

Free passage area (in cm²) / 122.8.

Material: Stainless steel (AISI 316).

Red interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 296.

B (in mm): 125.

C (in mm): 181.

D (in mm): 22.

Free passage area (in cm²) / 122.8.

Material: Stainless steel (AISI 316).

White interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 250.

B (in mm): 100.

C (in mm): 143.

D (in mm): 22.

Free passage area (in cm²) / 78.6.

Material: Stainless steel (AISI 316).

Red interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 250.

B (in mm): 100.

C (in mm): 143.

D (in mm): 22.

Free passage area (in cm²) / 78.6.

Material: Stainless steel (AISI 316).

White interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 205.

B (in mm): 75.

C (in mm): 123.

D (in mm): 22.

Free passage area (in cm²) / 44.2.

Material: Stainless steel (AISI 316).

Red interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 205.

B (in mm): 75.

C (in mm): 123.

D (in mm): 22.

Free passage area (in cm²) / 44.2.

Material: Stainless steel (AISI 316).

White interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 111.

B (in mm): 75.

C (in mm): 123.

D (in mm): 22.

Free passage area (in cm²) / 44.2.

Material: Stainless steel (AISI 316).

Red interior hood vent. 75mm inner diameter.

The handles and rings are made of cast stainless steel. The air sleeves are adjustable and removable.

The clamping ring can be tightened by hand. A threaded ring and a bridge ring are supplied as standard.

A mosquito net and a stainless steel cover for closing the hood fan are optional.

Technical characteristics:

A (in mm): 111.

B (in mm): 75.

C (in mm): 123.

D (in mm): 22.

Free passage area (in cm²) / 44.2.

Material: Stainless steel (AISI 316).

Dorade box for YOGI / SAMOEN, with mushroom fan.

Note: These boxes do not fit the S type fan.

This synthetic box drains any water entering the fan and can be closed completely using the built-in stainless steel mushroom fan.

The screw-on mounting ring supplied with the fan can be easily attached to the dorade box using the supplied bolts and nuts.

Dorade box for TOM / CHINOOK, with mushroom fan.

Note: These boxes do not fit the S type fan.

This synthetic box drains any water entering the fan and can be closed completely using the built-in stainless steel mushroom fan.

The screw-on mounting ring supplied with the fan can be easily attached to the dorade box using the supplied bolts and nuts.

Dorade box for DONALD / JERRY / TRAMON / LIBEC, with mushroom fan.

Note: These boxes do not fit the S type fan.

This synthetic box drains any water entering the fan and can be closed completely using the built-in stainless steel mushroom fan.

The screw-on mounting ring supplied with the fan can be easily attached to the dorade box using the supplied bolts and nuts.

This hood dorade box evacuates any water entering the interior of the boat through the air sleeve and can be closed completely by means of the incorporated mushroom vent in stainless steel (AISI 316).

Available in BOX75 synthetic material. Maximum deck thickness 25 mm.

Choose the same size BOX as the diameter (B) of the windsock.

CE marking: AII

Features :

Diameter (mm): 75.

Inner diameter of the tunnel (mm): 75.

This hood dorade box evacuates any water entering the interior of the boat through the air sleeve and can be closed completely by means of the incorporated mushroom vent in stainless steel (AISI 316).

Available in BOX100 synthetic material. Maximum deck thickness 25 mm.

Choose the same size BOX as the diameter (B) of the windsock.

CE marking: AII

Features :

Diameter (mm): 100.

Inner diameter of the tunnel (mm): 100.

BOXAD adapter flange suitable for aprons over 25 mm thick.

This flange can be mounted on the Dorade box using the counter flange, after which the adapter can be screwed onto the apron. The adapter flanges are made of bright polished AISI 316 stainless steel to fit stainless steel hood fans and Dorade boxes. Suitable for BOX75 and BOXS75

BOXAD adapter flange suitable for aprons over 25 mm thick.

This flange can be mounted on the Dorade box using the counter flange, after which the adapter can be screwed onto the apron. The adapter flanges are made of bright polished AISI 316 stainless steel to fit stainless steel hood fans and Dorade boxes. Suitable for BOX75 and BOXS75
