KIT MAJEUR POMPE SHERWOOD G1006/8

Kit réparation axe , roulements pour pompe à eau de moteur Volvo Penta série D3. suivants :
D3-110I-A, 110I-B, 110I-C
D3-130A-A, 130A-B, 130A-C, 130I-A, 130I-B, 130I-C
D3-160A-A, 160A-B, 160A-C, 160I-A, 160I-B, 160I-C
D3-190A-B, 190I-A, 190I-B, 190I-C
Sealing kit for the following Volvo Penta D3 engine water pumps:
D3-110I-D, 110I-E, 110I-F, 110I-G, 110I-H
D3-140A-D, 140A-E, 140A-F, 140A-G, 140A-H, 140I-E, 140I-F, 140I-G, 140I-H
D3-150I-D, 150I-E, 150I-G, 150I-H
D3-170A-D, 170A-E, 170A-F, 170A-G, 170A-H, 170I-D, 170I-E, 170I-F,
170I-G, 170I-H
D3-200A-D, 200A-E, 200A-F, 200A-G, 200A-H, 200I-D, 200I-E, 200I-F,
200I-G, 200I-H
D3-220A-D, 220A-E, 220A-F, 220A-G, 220A-H, 220I-D, 220I-E, 220I-F,
220I-G, 220I-H
Material also included in kit 22400.
Sea water pump cover, diameter 70mm, with 6 fixing screws.
Seawater pump kit for pump reference ST212.
Seawater pump repair kit in DAM reference: ST147 - ST149
Kit including the following positions:
6 Pump cover screws AP233
1 Oil seal 15247
1 Turbine 15811
1 Water pump cover AP2390
1 Water pump claw AP2393
1 Friction washer AP2395
Sea water pump cover, diameter 60mm, with 4 fixing screws.
Sea water pump cover, diameter 87mm, with 6 fixing screws.
Seawater pump repair kit including shaft for the following Volvo Penta engines:
MB10, D1, D2, D6
MB10A
MD1A, MD1B
AQD2B, D2A, MD2, MD2A, MD2B
MD6A
Add turbine 15807
Repair kit for Volvo Penta D12 - D16 seawater pump:
D12D-A MH
D12D-B MH
D12D-A MP, D12D-B MP, D12D-C MP, D12D-D MP, D12D-E MP, D12D-F MP
D12D-G MP, D12D-H MP D12D-C MH
D12C-A MP
D16C-A MH, D16C-B MH, D16C-C MH, D16C-A MG
Kit réparation pour pompe à eau de mer Volvo penta disposant d'un couvercle avec 5 vis de fixation et d'une turbine de type 15660.
Pensez au joints de remontage pour Volvo Penta série 40 :
2 pcs : 845354 joint tube d'eau
1 pcs : 968971 joint liaison pompe - bloc
Rajoutez la turbine 15660.
Kit joints d'étanchéité pour pompe à eau de mer sur Volvo 2003 turbo.
Water pump kit for the following Suzuki engines:
- DF9.9 DF15
- DT9.9 DT15
Water pump kit for the following engines:
- Yamaha: 55HP
- Mercury: 48 - 60HP
Pompe à eau de mer pour moteur Caterpillar 3196 et C12.
Seawater pump kit including shaft for Volvo B30 - D21 engine:
AQ165A
AQ170A, AQ170B, AQ170C
BB165
BB170A, BB170B, BB170C
AQD21A*, AQD21B
MD21A*, MD21B
Add turbine 15383.
Axle with a key.
Water pump kit for the following Mercury - Tohatsu engines:
Mercury: F8, F9.9 4-stroke 209CC with standard base
Tohatsu: MFS6, MFS8, MFS9.8, MFS9.9 4-stroke 2-cylinder
More complete kit than the AP7801 reference, including the bowl.
Kit couvercle incluant :
- Couvercle AP3364
- Rondelle de friction
- Joint spi 15247
- Bague plastique de maintien 844580
- Toriques
Couvercle pour montage avec joint torique.
Application Volvo Penta :
AD31L-A, AD31P-A, AD41A, AD41L-A
AD41P-A, D41L-A, KAD300-A, KAD32P
KAD42P-A, KAD43P-A, KAD43P-B, KAD44P
KAD44P-B, KAD44P-C, KAMD300-A, KAMD42P-A
KAMD43P, KAMD43P-A, KAMD43P-B, KAMD44P-A
KAMD44P-B, KAMD44P-C, TAMD31L-A, TAMD31M-A
TAMD31P-A, TAMD31S, TAMD41H-A, TAMD41H-B
TAMD41P, TAMD41P-A, TAMD42WJ-A, TMD31L-A
TMD41L-A
