Ref. DAM : DR002

SEMI-ELASTIC COUPLING DR002*

173.28 €173.28 VAT included
€144.40 VAT excluded
On demand
SEMI-ELASTIC COUPLING DR002*
SEMI-ELASTIC COUPLING DR002*
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
SEMI-ELASTIC COUPLING DR002*
SEMI-ELASTIC COUPLING DR002*
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
173.28 €173.28 VAT included
€144.40 VAT excluded

Molded polyurethane disc absorbs shock, vibration, noise, shaft thrust, and temporary misalignment. Electrically insulates the shaft. No wear or maintenance. Supplied with complete hardware.

Assignment: Yanmar

Number of CVs on the shaft line for 100 rpm: 3

For Diam. Crust: 101.6mm.

Centering: 50mm.

Outer diameter: 114.3 mm

Center distance: 78.00 mm

Thickness: 32.5 mm

Material: Polyurethane

Read the detailed description
Quantity
Free quote with no obligation
Response within 24 business hours
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Molded polyurethane disc absorbs shock, vibration, noise, shaft thrust, and temporary misalignment. Electrically insulates the shaft. No wear or maintenance. Supplied with complete hardware.

Assignment: Yanmar

Number of CVs on the shaft line for 100 rpm: 3

For Diam. Crust: 101.6mm.

Centering: 50mm.

Outer diameter: 114.3 mm

Center distance: 78.00 mm

Thickness: 32.5 mm

Material: Polyurethane
