List of products by brand QUICKSILVER

Quicksilver Plus engine pack 3.0l TKS series

Compatible with Alpha One bases only

Main features:

- TKS carburetor with mechanical fuel pump

- Multi-point draining

- Cast iron engine block,

- Dry joint cast iron exhaust manifold coated with electroplated paint,

- wet exhaust elbow,

- Raw water cooling

- Integrated rinsing system

- Accessory drive Trapezoidal belt

- Lubrication High Flow 60 psi oil pump

- Mechanical accelerator and reverse gear

- Harness with 10-pin connector

- Maximum speed 4800 / 135hp

- Cylinder capacity (CID/L) 181 / 3.0L

- Bore 101.60mm

- Compression ratio 9.3:1

- Alternator (amp/watt) 65 amp / 917 Watt

- Recommended Oil Mercury MerCruiser 25W-40 Synthetic Blend, NMMA Certified FC-W Synthetic Blend

- Hypereutectic alloy pistons

- Camshaft and roller tappet

- 1.5:1 stamped rocker arms

- Dimensions (L x W x H) 730 x 565 x 526 mm

- Weight (engine only) 257 kg

Mercury Marine and Quicksilver products carry a one-year factory warranty against defects. Items such as engines, drives, and plates must be installed by a dealer for the warranty to be valid.

Quicksilver Plus Engine Pack 350 Series MPI Bravo 300HP

Compatible with Bravo bases, this engine features optimal durability thanks to Black-X valve technology. Runs on 98 unleaded fuel, it is perfectly suited as a replacement for 5.0L, 5.7L carbureted engines with single-point injection and compatible with SmartCraft digital gauges.

Main features:

- Mercruiser GEN II fuel cooling,

- ECM 555,

- Engine Guardian Protection,

- Engine injection system Multipoint injection,

- Multi-point draining,

- Cast iron engine block,

- Dry joint cast iron exhaust manifold coated with electroplated paint,

- wet seal exhaust elbow,

- Cooling by raw water,

- Integrated rinsing system,

- Accessory drive Serpentine belt,

- Lubrication High Flow 60 psi oil pump,

- Mechanical accelerator and reverse gear,

- Harness with 10-pin connector,

- SmartCraft connector,

- Maximum speed 4800 - 5200 RPM, kW at the flywheel 300 / 224

- Cylinder capacity (CID/L) 350 / 5.7

- Bore and stroke 4.03 x 3.48" / 101.60 x 88 mm

- Compression ratio 9.4:1

- Tolerance to ethanol up to 10%.

- Alternator (amp/watt) 65 amp / 917 Watt

- Recommended Oil Mercury MerCruiser 25W-40 Synthetic Blend, NMMA Certified FC-W Synthetic Blend

- Hypereutectic alloy pistons

- Camshaft and roller tappet

- 1.5:1 stamped rocker arms

- Dimensions (L x W x H) 32 x 30 x 22" / 814 x 740 x 559 mm

- Weight (engine only) 423 kg / 932 lbs

Mercury Marine and Quicksilver products carry a one-year factory warranty against defects. Items such as engines, drives, and plates must be installed by a dealer for the warranty to be valid.

Quicksilver engine pack plus 350 series MPI Alpha 300CV

Compatible with ALPHA One GEN1 and GEN2 1.47:1 and 1.81:1 ratio bases, this engine features optimal durability thanks to Black-X valve technology. Runs on unleaded 98, it is perfectly suited as a replacement for 5.0L, 5.7L carbureted engines with single-point injection and compatible with SmartCraft digital gauges.

Main features:

- Mercruiser GEN II fuel cooling,

- ECM 555,

- Engine Guardian protection system,

- Engine injection system Multipoint injection,

- Multi-point draining,

- Cast iron engine block,

- Dry joint cast iron exhaust manifold coated with electroplated paint,

- wet seal exhaust elbow,

- Cooling by raw water,

- Integrated rinsing system,

- Accessory drive Serpentine belt,

- Lubrication High Flow 60 psi oil pump,

- Mechanical accelerator and reverse gear,

- Harness with 10-pin connector,

- SmartCraft connector,

- Maximum speed 4800 - 5200 RPM, kW at the flywheel 300 / 224

- Cylinder capacity (CID/L) 350 / 5.7

- Bore and stroke 4.03 x 3.48" / 101.60 x 88 mm

- Compression ratio 9.4:1

- Tolerance to ethanol up to 10%.

- Alternator (amp/watt) 65 amp / 917 Watt

- Recommended Oil Mercury MerCruiser 25W-40 Synthetic Blend, NMMA Certified FC-W Synthetic Blend

- Hypereutectic alloy pistons

- Camshaft and roller tappet

- 1.5:1 stamped rocker arms

- Dimensions (L x W x H) 32 x 30 x 22" / 814 x 740 x 559 mm

- Weight (engine only) 423 kg / 932 lbs

NOTE: If used with an Alpha One (GEN1) engine, this engine requires Seawater Pump Kit 46-8M0139983 and Serpentine Belt 57-865615Q03 (sold separately) for proper cooling.

Mercury Marine and Quicksilver products carry a one-year factory warranty against defects. Items such as engines, drives, and plates must be installed by a dealer for the warranty to be valid.

Quicksilver maintenance kit for SUZUKI engines:

- DF200 - 225 - 250 - V6.

- DF250A - 250AP.

- DF250SS.

- DF300A - AP.

- DF300B - 300BMD.

- DF350A - 350AMD.

Including:

- Oil filter 8M0154773

- Fuel filters 8M0154756

- Engine drain gasket 8M6013379

- Base drain gaskets 8M6012807
