Engine mounts for marine engines - Page 2

Yanmar Barry type engine mount.

Engine mount with the following characteristics:

Center distance 100mm with

19mm threaded rod.

Support height 47mm

height of threaded rod included 70mm.

For a 16mm threaded rod see reference BA8/0001.

Volvo base silent block with a center distance of 125MM for the following applications:

280B

290A, 290DP

DP-A, DP-A1, DP-A2

DP-B, DP-B1

DP-C, DP-C1, DP-C1

DP-D, DP-D1 1.68, DP-D1, DP-D1

SP-A, SP-A1, SP-A2

SP-C, SP-C1

Complete fixing kit including washers, nut and threaded rod for SP6043 M20 series motor mount.

HD mounting kits allow for finer alignment than standard mounting kits.

Due to their design, the HD kits offer the capacity to line 5 to 10 mm depending on the thread. (10 mm for M20).

The lower nut support area offers a larger surface area, making adjustment easier, more precise and more durable over time. 48 hours of adjustment is required before locking the entire unit.

These kits meet the needs of recent high-revving engines.

Thickness shim for SP171609 series engine mount allowing the alignment to be raised by 4mm in a lasting manner.

DNV standards state that the only way to properly level engine mounts is to use shims above 4mm.

Center distances: 145mm

Width: 75mm

Thickness shim for SP136003 series engine mount allowing alignment to be raised by 4mm in a lasting manner.

DNV standards state that the only way to properly level engine mounts is to use shims above 4mm.

Center distances: 100mm

Width: 60mm

Complete rear engine mount with PCM inverters of types:

- Velvet drive 1:1 and 1.52:1

- PCM 1:1

- PCM Ford and GM

Dimensions:

- Height: 41.5 and 77mm

- Bottom diameter: 74mm

- Center distance: 101mm

- Axle: 12mm

SHORE 60

Silent block for Volvo base with a center distance of 85MM.

Nut included.

Volvo Penta base application:

AQ270, AQ270T, AQ275A, AQ280

AQ280T, AQ280DP, AQ285A, SP-A/MT

SPA

Rear engine mount for Yanmar engines with a saildrive base type SD20 - SD25 or SD30.

Engine applications: 3YM20, 3YM30, 3GM30 and 3HM35.

Note on rubber / engraved: 230

Maximum load: 150 kg

Complete PCM engine mount with a 25mm diameter and 64mm length axle.

Hardware including R092011 support.

Double motor mount for Crusader motor with a 25.5mm diameter axle.

The 22mm diameter supports are removed from production.

Silent block for Volvo Penta engines of series 40 - 41 -42 in particular.

Features :

- Total height: 55mm

- Diameter: 75mm

- Center distance: 105mm

- Thread: M16 fine pitch

Mounting kit under reference 22323-1 to be used only for this series of engine mounts.

Less center distance than the SP171609 series brackets.

Engine mount for universal application but especially Volvo Penta with the following characteristics:

Center distance: 140mm

Width: 75mm

Total height: 50mm

Hardness: 45

Thread: M16

Support to be used in addition to the SP181609 fixing kit.

Complete Indmar rear motor mount for Velvet drive and Hurth- ZF direct type inverters.

Support for Volvo Penta shore 60 engines with a blue marking:

D4-150A-G, D4-175I-G, D4-230A-G, D4-230I-G

D4-270A-G, D4-270I-G, D4-300A-G, D4-300I-G

D4-320A-G, D4-320I-G, D6-280A-A, D6-280A-B

D6-280A-C, D6-280A-D, D6-280A-E, D6-280I-A

D6-280I-B, D6-280I-C, D6-280I-D, D6-280I-E

D6-280I-E, D6-300A-F, D6-300A-G, D6-300D-F

D6-300D-G, D6-300I-F, D6-300I-G, D6-310A-A

D6-310A-B, D6-310A-C, D6-310A-D, D6-310A-E

D6-310D-B, D6-310D-C, D6-310D-D, D6-310D-E

D6-310I-A, D6-310I-A, D6-310I-B, D6-310I-C

D6-310I-C, D6-310I-D, D6-310I-E, D6-330A-B

D6-330A-C, D6-330A-D, D6-330A-E, D6-330A-F

D6-330D-C, D6-330D-D, D6-330D-E, D6-330D-F

D6-330I-B, D6-330I-C, D6-330I-D, D6-330I-E

D6-330I-F, D6-340A-G, D6-340D-G, D6-340I-G

D6-350A-A, D6-350A-B, D6-370A-C, D6-370A-D

D6-370A-E, D6-370A-F, D6-370D-B, D6-370D-C

D6-370D-D, D6-370D-E, D6-370D-F, D6-370I-A

D6-370I-B, D6-370I-C, D6-370I-D, D6-370I-E

D6-370I-F, D6-380A-G, D6-380D-G, D6-380I-G

D6-400A-E, D6-400A-F, D6-400A-G, D6-435D-C

D6-435D-D, D6-435D-E, D6-435D-F, D6-435I-A

D6-435I-A, D6-435I-C, D6-435I-D, D6-435I-E

D6-435I-F, D6-440A-G, D6-440D-G, D6-440I-G

D6-440I-WJ-G, D6-480D-G, D6-480I-G, D6-480I-WJ-G

Front engine mount for Yanmar 1GM - 1GM10 series.

Engine mount for Volvo Penta.

SHORE 70 - 140KG

Volvo App:

Engines with a PRM inverter bell

2002, 2002AG, 2002B, 2002BG, 2002D

2003, 2003AG, 2003B, 2003BG, 2003D

2003T, 2003TB

MD11C, MD11D

MD17C, MD17D

MD2020A, MD2020B, MD2020C, MD2020D - SAILDRIVE

MD2030A, MD2030B, MD2030C, MD2030D - SAILDRIVE

Locking axle for PCM and INDMAR engine mount.

Nut to be added if necessary RS1529.

Silent block kit present in the coupling bell of Mercruiser BB and diesel engines.

Dimensions :

24mm épaisseur

45mm diamètre au plus étroit

52mm diamètre au plus large

68cm hauteur avec filetage

Engine mount for Yanmar with the following features:

- Length: 205mm

- Width: 60mm

- Total height: 147mm

- Body height: 75mm

- Threaded rod: M16 X 1.5

- Center distance: 173mm

- Note on rubber: 300
