This page allows you to view the exploded diagrams for the Yamaha f8cmhs - 2004 4-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a recognised brand in the outboard engine industry. It offers engines designed to meet the requirements of recreational boaters and professionals, with ranges suited to maintenance, repair and marine use.

Un doute?  > contact us

Select an exploded diagram for your Yamaha f8cmhs - 2004 4-stroke engine

Yamaha f8cmhs - 2004 engine 8 HP 4-stroke

Yamaha f8cmhs - 2004

The Yamaha f8cmhs - 2004 is a 4-stroke outboard engine producing 8 HP. Its mechanical design is based on a 212 cm³ in-line twin-cylinder SOHC engine with a 56.0 mm bore and a 43.0 mm stroke.

Its intake system uses one carburettor, combined with wet-sump lubrication holding 0.8 L of engine oil. CDI ignition and a 6 A alternator fitted with a rectifier-regulator support the operation of this compact engine.

The exploded diagrams for the Yamaha f8cmhs - 2004 show how the components are arranged before servicing begins. They help locate compatible parts, understand their position within each assembly and identify the references required for maintenance or repair.

Yamaha f8cmhs - 2004 engine features
  • 8 HP output delivered by a compact 4-stroke outboard engine
  • In-line twin-cylinder SOHC layout designed around two cylinders
  • 212 cm³ displacement with a bore and stroke of 56.0 × 43.0 mm
  • Carburettor fuel system combined with wet-sump lubrication
  • 6 A alternator with CDI ignition and a rectifier-regulator

View exploded diagrams Yamaha f8cmhs - 2004

View all compatible parts
