This page allows you to view the exploded diagrams for the Yamaha f40b - 2007 4-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a well-known brand in the outboard engine industry. It offers engines designed to meet the needs of recreational and professional users, with ranges suited to maintenance, repair and operation in marine environments.

Un doute?  > contact us

Select an exploded diagram for your Yamaha f40b - 2007 4-stroke engine

Yamaha f40b - 2007 40 HP 4-stroke engine

Yamaha f40b - 2007

The Yamaha f40b - 2007 is a 40 HP 4-stroke outboard featuring an inline three-cylinder engine with an SOHC valve layout. Its 747 cm³ displacement is combined with a fuel injection system that supplies the engine throughout the different stages of operation.

This model uses CDI ignition and wet-sump lubrication. It is also equipped with a 17 A alternator, including 13 A of battery-charging capacity, and may be configured with either a 15-inch short shaft or a 20-inch long shaft depending on the installation.

The exploded diagrams for the Yamaha f40b - 2007 make it easier to locate parts and understand their position within the mechanical assemblies. They provide useful support when identifying compatible part numbers before maintenance or repair work.

Yamaha f40b - 2007 engine specifications
  • 40 HP 4-stroke engine intended for a range of outboard boating applications
  • Inline three-cylinder SOHC design arranged within a compact mechanical layout
  • 747 cm³ displacement with a 65.0 × 75.0 mm bore and stroke
  • Fuel injection system designed to meter fuel accurately
  • CDI ignition and 17 A alternator with 13 A available for battery charging

View exploded diagrams Yamaha f40b - 2007

View all compatible parts

Exploded views
