This page allows you to view the exploded diagrams for the Yamaha e40xmhl - 2005 2-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a well-known brand in the outboard engine industry. It offers engines designed to meet the needs of recreational and professional users, with ranges suited to maintenance, repairs and operation in marine environments.

Un doute?  > contact us

Select an exploded diagram for your Yamaha e40xmhl - 2005 2-stroke engine

Yamaha e40xmhl - 2005 engine 40 HP 2-stroke

Yamaha e40xmhl - 2005

The Yamaha e40xmhl - 2005 is a 40 HP 2-stroke outboard engine that reaches its maximum output at 5,000 rpm. Its mechanical design features two in-line cylinders, a displacement of 703 cm³ and a full-throttle operating range of 4,500 to 5,500 rpm.

Steering is handled through a tiller handle, combined with manual starting and a manual tilt system. Carburettor fuel delivery, CDI ignition and a 2.00 (26/13) reduction ratio are among the main elements of its mechanical configuration.

Viewing the exploded diagrams makes it possible to distinguish each assembly of the Yamaha e40xmhl - 2005 and locate components before carrying out work. These diagrams simplify the selection of compatible parts and the checking of references required for routine maintenance or engine repairs.

Yamaha e40xmhl - 2005 engine specifications
  • Maximum output of 40 HP delivered at an engine speed of 5,000 rpm
  • In-line two-cylinder design providing a total displacement of 703 cm³
  • Full-throttle range of 4,500 to 5,500 rpm for engine operation
  • Tiller handle and manual starting completed by a manual tilt system
  • 100:1 pre-mixed lubrication using fuel and 2-stroke engine oil

View exploded diagrams Yamaha e40xmhl - 2005
