This page allows you to view the exploded diagrams for the Yamaha e40gmhl - 2013 2-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a recognised brand in the outboard engine industry. It offers engines designed to meet the needs of recreational boaters and professionals, with ranges suited to maintenance, repair and marine use.

Un doute?  > contact us

Select an exploded diagram for your Yamaha e40gmhl - 2013 2-stroke engine

Yamaha e40gmhl - 2013 40 HP 2-stroke engine

Yamaha e40gmhl - 2013

The Yamaha e40gmhl - 2013 uses a 2-stroke outboard configuration with two cylinders arranged in line. With a displacement of 703 cm³, it produces a maximum output of 29.4 kW, equivalent to 40 HP at 5,000 rpm.

Fuel delivery is handled by a carburettor, while a CDI system controls ignition. Lubrication relies on oil and fuel being pre-mixed, and the cylinder geometry is defined by an 80.0 mm bore and a 70.0 mm stroke.

The exploded diagrams make it possible to inspect the engine assemblies separately and locate individual components before servicing. They simplify part-number identification and the selection of compatible parts for maintaining or repairing the Yamaha e40gmhl - 2013.

Yamaha e40gmhl - 2013 engine specifications
  • 40 HP output delivered at an engine speed of 5,000 rpm
  • 703 cm³ displacement provided by two cylinders positioned in line
  • 2-stroke engine design using a pre-mixed lubrication system
  • Carburettor and CDI ignition managing fuel delivery and ignition control
  • 80.0 mm bore and 70.0 mm stroke corresponding to the internal cylinder dimensions

View exploded diagrams Yamaha e40gmhl - 2013
