This page allows you to view the exploded diagrams for the Yamaha e40gmhl - 2003 2-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a recognised brand in the outboard engine industry. It offers engines designed to meet the needs of recreational boaters and professionals, with ranges suited to maintenance, repair and marine use.

Un doute?  > contact us

Select an exploded diagram for your Yamaha e40gmhl - 2003 2-stroke engine

Yamaha e40gmhl - 2003 40 HP 2-stroke engine

Yamaha e40gmhl - 2003

The Yamaha e40gmhl - 2003 delivers a maximum output of 40 HP at 5,000 rpm, equivalent to 29.4 kW at the propeller shaft. This 2-stroke outboard engine uses an in-line two-cylinder configuration with a total displacement of 703 cm³.

Its operating design combines a carburettor fuel system with CDI ignition. Lubrication requires fuel and oil to be mixed beforehand, while the 80.0 mm bore and 70.0 mm stroke define the internal cylinder dimensions.

The exploded diagrams provide a detailed view of the mechanical assemblies and their individual components. They make it easier to locate parts, verify reference numbers and choose the correct compatible parts for maintaining or repairing the Yamaha e40gmhl - 2003.

Yamaha e40gmhl - 2003 engine specifications
  • Maximum output of 29.4 kW equivalent to 40 HP at an engine speed of 5,000 rpm
  • Two in-line cylinders providing a total displacement of 703 cm³
  • 2-stroke operation with lubrication supplied through a pre-mixed system
  • Carburettor and CDI ignition handling fuel delivery and ignition respectively
  • 80.0 × 70.0 mm bore and stroke corresponding to the engine’s internal dimensions

View exploded diagrams Yamaha e40gmhl - 2003

View all compatible parts
