Parts and exploded diagrams for Yamaha e40gmhl - 2017 2-stroke engine
This page allows you to view the exploded diagrams for the Yamaha e40gmhl - 2017 2-stroke engine and easily identify the compatible parts for your engine.
Yamaha is a well-known brand in the outboard engine industry. It offers engines designed to meet the requirements of recreational boaters and professionals, with ranges suited to maintenance, repairs and use in marine environments.
Select an exploded diagram for your Yamaha e40gmhl - 2017 2-stroke engine
Yamaha e40gmhl - 2017
The Yamaha e40gmhl - 2017 is a 40 HP 2-stroke outboard engine based on an in-line two-cylinder design. Its 703 cm³ engine block has an 80.0 x 70.0 mm bore and stroke and delivers a maximum propeller-shaft output of 29.4 kW (40 HP) at 5,000 rpm.
Its fuel system uses a carburettor, while lubrication requires fuel and oil to be mixed before operation. Depending on the engine configuration, the equipment may include manual or manual and electric starting, tiller-handle or remote-control operation and either manual tilt or Power Trim & Tilt.
The exploded diagrams make it possible to examine the different mechanical assemblies of the Yamaha e40gmhl - 2017 and see the position of each component. They provide useful support for checking part numbers, confirming component compatibility and selecting the correct compatible spare parts for maintenance or repair.
Yamaha e40gmhl - 2017 engine specifications- 40 HP output delivered at the propeller shaft at an engine speed of 5,000 rpm
- In-line twin-cylinder layout combined with a 2-stroke operating cycle
- 703 cm³ displacement with internal dimensions of 80.0 x 70.0 mm
- Carburettor fuel delivery and lubrication provided by a pre-mixed fuel and oil blend
- Equipment varying by model for starting, controls and engine tilt
View exploded diagrams Yamaha e40gmhl - 2017
