This page allows you to view the exploded diagrams for the Yamaha e15dmhl - 2018 2-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a well-known brand in the outboard engine industry. It offers engines designed to meet the needs of both recreational and professional users, with ranges suited to maintenance, repair and operation in marine environments.

Un doute?  > contact us

Select an exploded diagram for your Yamaha e15dmhl - 2018 2-stroke engine

Yamaha e15dmhl - 2018 engine 15 HP 2-stroke

Yamaha e15dmhl - 2018

The Yamaha e15dmhl - 2018 is built around an in-line two-cylinder 246 cm³ 2-stroke engine. This outboard produces 15 HP at 5,000 rpm, equivalent to a maximum propeller-shaft output of 11.0 kW, with a 56.0 mm bore and a 50.0 mm stroke.

Fuel delivery is handled by a carburettor, while lubrication requires a pre-mixed blend of fuel and oil. The engine is operated through a tiller handle, and both starting and tilting are manual. Two configurations are available, with a 440 mm transom height for the S version and 567 mm for the L version.

The exploded diagrams visually separate the mechanical assemblies to make the part involved in a repair easier to locate. They help confirm part numbers and select the correct compatible parts for servicing or repairing the Yamaha e15dmhl - 2018.

Yamaha e15dmhl - 2018 engine specifications
  • 15 HP at 5,000 rpm representing 11.0 kW at the propeller shaft
  • 246 cm³ in-line two-cylinder engine operating on a 2-stroke cycle
  • Carburettor fuel delivery with lubrication provided by a pre-mixed blend of fuel and oil
  • Tiller-handle operation with manual starting and a manual tilt mechanism
  • S and L configurations for 440 or 567 mm transom heights, weighing 36.0 or 37.5 kg

View exploded diagrams Yamaha e15dmhl - 2018

View all compatible parts
