Parts and exploded diagrams for Yamaha 9.9f - 2001 2-stroke engine

Parts and exploded diagrams for Yamaha 9.9f - 2001 2-stroke engine

Yamaha logo

This page allows you to view the exploded diagrams for the Yamaha 9.9f - 2001 2-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a well-known brand in the outboard engine industry. It offers engines designed to meet the needs of recreational boaters and professionals, with ranges suitable for maintenance, repair and use in marine environments.

Un doute?  > contact us

Select an exploded diagram for your Yamaha 9.9f - 2001 2-stroke engine

Yamaha 9.9f - 2001 9.9 HP 2-stroke engine

Yamaha 9.9f - 2001

The Yamaha 9.9f - 2001 is a 9.9 HP 2-stroke outboard producing its maximum output at 5,000 rpm. It features a 246 cm³ in-line two-cylinder layout with a bore and stroke of 56.0 x 50.0 mm, delivering 7.3 kW at the propeller shaft.

This engine is equipped with a carburetor fuel system and is operated through a tiller handle. Its manual starting system, manual tilt mechanism and lubrication based on pre-mixed fuel and oil provide a straightforward mechanical configuration for routine servicing.

Viewing the exploded diagrams for the Yamaha 9.9f - 2001 makes it easier to understand how the components are arranged and locate the part involved in a repair. The diagrams also help identify compatible references before replacing a component or carrying out maintenance.

Yamaha 9.9f - 2001 engine specifications
  • 246 cm³ displacement distributed across two cylinders arranged in line
  • Maximum output of 9.9 HP reached at an engine speed of 5,000 rpm
  • Tiller-handle controls for direct steering and engine operation
  • Manual tilt system used to adjust the outboard position by hand
  • Pre-mixed fuel and oil providing lubrication for the 2-stroke engine

View exploded diagrams Yamaha 9.9f - 2001

View all compatible parts

Exploded views
