Parts and exploded diagrams for Yamaha 40vmhol - 2017 2-stroke engine
This page allows you to view the exploded diagrams for the Yamaha 40vmhol - 2017 2-stroke engine and easily identify the compatible parts for your engine.
Yamaha is a recognised brand in the outboard engine industry. It offers engines designed to meet the needs of both recreational boaters and professionals, with ranges suited to maintenance, repairs and use in marine environments.
Select an exploded diagram for your Yamaha 40vmhol - 2017 2-stroke engine
Yamaha 40vmhol - 2017
The Yamaha 40vmhol - 2017 produces a maximum output of 40 HP at 5,000 rpm, corresponding to 29.4 kW. This 2-stroke outboard engine uses an in-line twin-cylinder configuration with a total displacement of 703 cm³, an 80.0 mm bore and a 70.0 mm stroke.
Its full-throttle operating range extends from 4,500 to 5,500 rpm, while the neutral idle speed is specified at 1,000 ± 50 rpm. The engine combines carburettor fuel delivery, CDI ignition, NGK BR7HS spark plugs and a lubrication system using a pre-mixed combination of fuel and oil.
By detailing each mechanical group, the exploded diagrams make the component arrangement easier to understand and help locate a part that needs inspection or replacement. They simplify the search for references suited to the Yamaha 40vmhol - 2017, compatible-part checks and the preparation of maintenance or repair work.
Yamaha 40vmhol - 2017 engine specifications- Maximum output of 29.4 kW corresponding to 40 HP delivered at an engine speed of 5,000 rpm
- In-line twin-cylinder 2-stroke engine providing a total displacement of 703 cm³
- 80.0 × 70.0 mm internal dimensions corresponding to the bore and stroke respectively
- Carburettor fuel delivery and CDI ignition combined with NGK BR7HS spark plugs featuring a 0.6 to 0.7 mm gap
- Transmission with a 2.00 reduction ratio including forward, neutral and reverse positions
View exploded diagrams Yamaha 40vmhol - 2017
