This page allows you to view the exploded diagrams for the Yamaha 2cmhs - 2010 2-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a recognised brand in the outboard engine industry. It offers engines designed to meet the requirements of both recreational boaters and professionals, with ranges suited to maintenance, repair and use in marine environments.

Un doute?  > contact us

Select an exploded diagram for your Yamaha 2cmhs - 2010 2-stroke engine

Yamaha 2cmhs - 2010

The Yamaha 2cmhs - 2010 is a 2 HP 2-stroke outboard engine producing 1.5 kW at 4,500 rpm. Its single-cylinder power unit has a displacement of 50 cm³ and a bore and stroke measurement of 42 × 36 mm.

Operation is based on a manual starting system and tiller control. The engine also features one carburettor, reed-valve induction, CDI ignition and water cooling. Lubrication is provided through a pre-mixed combination of fuel and oil.

The exploded diagrams provide a detailed view of the assemblies and the position of individual engine components. They help locate the correct references and select the compatible parts required for servicing or repairing the Yamaha 2cmhs - 2010.

Yamaha 2cmhs - 2010 engine features
  • 2 HP output, equivalent to 1.5 kW at 4,500 rpm
  • 50 cm³ single-cylinder 2-stroke engine with an 8.30:1 compression ratio
  • Full-throttle operating range from 4,000 to 5,000 rpm
  • Manual starting and tiller control combined with 360° steering
  • CDI ignition and water cooling with a pre-mixed fuel-and-oil lubrication system

See the exploded views “Yamaha 2cmhs - 2010”
