This page allows you to view the exploded diagrams for the Yamaha 200aetl - 2025 2-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a well-known brand in the outboard engine industry. It offers engines designed to meet the needs of both recreational boaters and professionals, with ranges suited to maintenance, repair and use in marine environments.

Un doute?  > contact us

Select an exploded diagram for your Yamaha 200aetl - 2025 2-stroke engine

Yamaha 200aetl - 2025 200 HP 2-stroke engine

Yamaha 200aetl - 2025

The Yamaha 200aetl - 2025 is a 2-stroke outboard delivering a maximum output of 200 HP at 5,000 rpm. Its 90° V6 block contains six cylinders and has a displacement of 2,596 cm³, with a 90 mm bore and a 68 mm stroke.

The full-throttle operating range extends from 4,500 to 5,500 rpm. Fuel is supplied through carburettors, while electric starting, remote controls and the Power Trim & Tilt system support engine operation, trim adjustment and lifting.

For maintenance and repair work, the exploded diagrams show how the different components are arranged and where each part is located. They make it easier to find compatible parts and identify the references suited to the Yamaha 200aetl - 2025.

Yamaha 200aetl - 2025 engine features
  • 200 HP at 5,000 rpm for applications requiring a powerful outboard engine
  • 90° V6 configuration with six cylinders and a total displacement of 2,596 cm³
  • Operating range of 4,500 to 5,500 rpm corresponding to the recommended full-throttle range
  • Carburettor fuel system combined with equipment suited to 2-stroke operation
  • Remote control, electric start and Power Trim & Tilt for managing and positioning the engine

View exploded diagrams Yamaha 200aetl - 2025

View all compatible parts
