Parts and exploded diagrams for Yamaha 15f - 1995 2-stroke engine
This page allows you to view the exploded diagrams for the Yamaha 15f - 1995 2-stroke engine and easily identify the compatible parts for your engine.
Yamaha is a recognised brand in the outboard engine industry. It offers engines designed to meet the needs of recreational and professional users, with ranges suited to maintenance, repairs and use in marine environments.
Select an exploded diagram for your Yamaha 15f - 1995 2-stroke engine
Yamaha 15f - 1995
The Yamaha 15f - 1995 is a 15 HP 2-stroke outboard powered by a 246 cm³ inline twin-cylinder engine. Its 56.0 x 50.0 mm bore and stroke configuration delivers a maximum propeller-shaft output of 11.0 kW, equivalent to 15 HP, at 5,000 rpm.
This engine features a carburettor fuel system and uses pre-mixed fuel and oil for lubrication. Its manual starting system, tiller-handle controls and manual tilt provide a straightforward operating configuration, while its dry weight ranges from 36 to 38 kg.
The exploded diagrams help locate the engine’s assemblies and individual components before maintenance or repair work begins. They also make it easier to identify part numbers and select compatible parts for the Yamaha 15f - 1995, including components associated with the S and L transom-height versions.
Yamaha 15f - 1995 engine specifications- 15 HP output produced at 5,000 rpm, with a maximum propeller-shaft output of 11.0 kW
- 246 cm³ inline twin-cylinder engine featuring a bore and stroke of 56.0 x 50.0 mm
- Carburettor fuel induction combined with a pre-mixed fuel-and-oil lubrication system
- Tiller-handle controls supported by manual starting and manual tilt systems
- S and L shaft versions for transom heights of 440 mm or 567 mm, with a dry weight of 36 to 38 kg
View exploded diagrams Yamaha 15f - 1995
