This page allows you to view the exploded diagrams for the Yamaha 115c - 1998 2-stroke engine and easily identify the compatible parts for your engine.

Yamaha is a recognised brand in the outboard engine industry. It offers engines designed to meet the needs of recreational boaters and professionals, with ranges suited to maintenance, repairs and use in marine environments.

Un doute?  > contact us

Select an exploded diagram for your Yamaha 115c - 1998 2-stroke engine

Yamaha 115c - 1998

The Yamaha 115c - 1998 is a 115 HP 2-stroke outboard using a four-cylinder engine arranged in a 90° V configuration. Its 1,730 cm³ displacement, produced by a 90 mm bore and 68 mm stroke, is paired with an operating range of 4,500 to 5,500 rpm.

Its equipment includes electric starting, remote control and a CDI ignition system. Yamaha Autolube automatically supplies oil to the engine, while the power trim and tilt system is used to adjust the outboard angle according to the boat’s running position and boating conditions.

The exploded diagrams make it possible to inspect each mechanical assembly separately and understand how the components fit together. They provide valuable support for locating a part, checking its reference and selecting the correct compatible parts for maintenance or repair work.

Yamaha 115c - 1998 engine specifications
  • 115 HP output intended for a boat suited to this engine capacity
  • Four-cylinder 2-stroke engine arranged in a 90° V configuration
  • 1,730 cm³ displacement with a 90 mm bore and 68 mm stroke
  • Remote control and electric starting for operation from the helm position
  • 2.00 gear ratio with forward, neutral and reverse positions

View exploded diagrams Yamaha 115c - 1998

View all compatible parts
