Parts and exploded diagrams for Volvo penta d70crc engine
This page allows you to view the exploded diagrams for the Volvo penta d70crc Inboard engine, belonging to the 6-cylinder category, and easily identify compatible parts for your engine.
Volvo Penta is a brand specialising in marine propulsion solutions. These exploded diagrams help identify the components and references required for the maintenance and repair of Inboard engines.
Select an exploded diagram for your Volvo penta d70crc inboard engine
Volvo penta d70crc
The Volvo penta d70crc Inboard engine is part of the 6-cylinder category. Its supplied specifications include a displacement of 6.73 litres, together with a 104.77 mm bore and a 130 mm stroke.
A compression ratio of 17:1 is specified for this configuration. The engine also has an approximate weight of 670 kg when considered without gearbox or coupling, providing useful reference information for servicing and repair work.
Exploded diagrams make it easier to locate the engine’s individual assemblies and mechanical components. They help users identify the correct references for compatible parts and prepare maintenance, inspection or replacement operations more efficiently.
Volvo penta d70crc engine specifications- Stroke: 130 mm according to the available technical data
- Displacement: 6.73 litres for the stated total engine capacity
- Weight: approximately 670 kg without gearbox or coupling
- Bore: 104.77 mm corresponding to the cylinder diameter
- Compression ratio: 17:1 according to the supplied specifications
View exploded diagrams Volvo penta d70crc
