Parts and exploded diagrams for Volvo penta d70b engine
This page allows you to view the exploded diagrams for the Volvo penta d70b Inboard engine, belonging to the 6-cylinder category, and easily identify compatible parts for your engine.
Volvo Penta is a brand specialising in marine propulsion solutions. These exploded diagrams help identify the components and references required for the maintenance and repair of Inboard engines.
Select an exploded diagram for your Volvo penta d70b inboard engine
Volvo penta d70b
The Volvo penta d70b Inboard engine belongs to the 6-cylinder category. The supplied technical specifications state a 104.77 mm bore and a 130 mm stroke, resulting in a total displacement of 6.73 litres.
For the D70B version, the specified compression ratio is 17:1. The approximate engine weight without gearbox or coupling is 670 kg. These figures provide useful reference points when carrying out servicing, inspections and mechanical work.
Exploded diagrams provide access to the engine's different assemblies, including the cylinder block, cylinder head, injection, cooling, lubrication and electrical components. They make it easier to identify references and select compatible parts required for maintenance or repair.
Volvo penta d70b engine specifications- Displacement: 6.73 litres for the stated total engine capacity
- Bore: 104.77 mm corresponding to the cylinder diameter
- Stroke: 130 mm according to the supplied technical specifications
- Compression ratio: 17:1 for the D70B version
- Weight: approximately 670 kg without gearbox or coupling
View exploded diagrams Volvo penta d70b
