Parts and exploded diagrams for Volvo penta bb170a engine
This page allows you to view the exploded diagrams for the Volvo penta bb170a Inboard engine, belonging to the 6-cylinder category, and easily identify compatible parts for your engine.
Volvo Penta is a brand specialising in marine propulsion solutions. These exploded diagrams make it easier to identify the components and references required for the maintenance and repair of Inboard engines.
Select an exploded diagram for your Volvo penta bb170a inboard engine
Volvo penta bb170a
The Volvo penta bb170a is a four-stroke marine Inboard engine in the 6-cylinder category, rated at 170 HP at 5,000 rpm. Its 2.979-litre displacement and inline six-cylinder layout are combined with a compact design intended for marine installations.
Fuel delivery is handled by three Solex down-draft carburettors connected in parallel, each equipped with two fixed jets and an acceleration pump. The engine also features a water-cooled exhaust manifold and can be fitted with a hydraulically actuated reverse/reduction gear with a standard ratio of 1.91:1 and alternative ratios of 2.1:1 or 2.91:1.
For maintenance or repair work on the Volvo penta bb170a, exploded diagrams help locate the various mechanical, electrical, fuel and cooling assemblies. They therefore simplify part-number identification and the selection of compatible parts required for accurate servicing of the engine.
Volvo penta bb170a engine specifications- Output: 170 HP at 5,000 rpm, the stated rating for this four-stroke marine engine
- Displacement: 2.979 litres, with an 88.9 × 80 mm bore and stroke
- Layout: inline 6-cylinder, the configuration explicitly specified for the BB170 A
- Fuel system: three Solex carburettors, connected in parallel with acceleration pumps
- Hydraulically actuated reverse/reduction gear, with a standard 1.91:1 ratio and optional 2.1:1 or 2.91:1 ratios
View exploded diagrams Volvo penta bb170a
