Parts and exploded diagrams for Volvo penta aqd70d engine
This page allows you to view the exploded diagrams for the Volvo penta aqd70d Inboard engine, belonging to the 6-cylinder category, and easily identify compatible parts for your engine.
Volvo Penta is a brand specialising in marine propulsion solutions. These exploded diagrams make it easier to identify components and references required for the maintenance and repair of Inboard engines.
Select an exploded diagram for your Volvo penta aqd70d inboard engine
Volvo penta aqd70d
Designed for marine Inboard use, the Volvo penta aqd70d belongs to the 6-cylinder category. The supplied specifications state a displacement of 6.73 litres and a power output of 184 kW (250 HP). This diesel engine operates on a four-stroke cycle and is part of the Volvo Penta 70 Series.
Fuel delivery is based on direct injection, combined with a thermostatically controlled cooling system. On marine engines from this series, temperature management uses both freshwater and seawater circuits connected through a heat exchanger. The engine also includes components associated with the turbocharger, injectors, pumps, fuel supply and cooling systems.
When servicing or repairing the Volvo penta aqd70d, exploded diagrams help identify each assembly and the components within it. They make it easier to locate suitable references for the various engine systems, including fuel supply, lubrication, cooling and electrical equipment, helping users select the correct compatible parts.
Volvo penta aqd70d engine specifications- Power: 184 kW (250 HP) according to the supplied technical data
- Fuel: diesel with four-stroke engine operation
- Category: 6-cylinder corresponding to the specified number of cylinders
- Displacement: 6.73 l for the stated total engine displacement
- Direct injection used to supply fuel to the engine
View exploded diagrams Volvo penta aqd70d
