Parts and exploded diagrams for Volvo penta aqd70c engine
This page allows you to view the exploded diagrams for the Volvo penta aqd70c Inboard engine, belonging to the 6-cylinder category, and easily identify compatible parts for your engine.
Volvo Penta is a brand specialising in marine propulsion solutions. These exploded diagrams make it easier to identify components and references required for the maintenance and repair of Inboard engines.
Select an exploded diagram for your Volvo penta aqd70c inboard engine
Volvo penta aqd70c
The Volvo penta aqd70c is a marine Inboard engine in the 6-cylinder category. The supplied specifications state a displacement of 6.73 litres and an output of 184 kW (250 HP). It is a four-stroke diesel engine belonging to the Volvo Penta 70 Series.
This engine uses direct fuel injection and a thermostatically controlled cooling system. On marine engines from this series, the cooling arrangement combines freshwater and seawater circuits through a heat exchanger. Its systems include components associated with the turbocharger, fuel supply, injectors, pumps and engine cooling.
For Volvo penta aqd70c maintenance, exploded diagrams provide a clear view of the main assemblies and help locate components that may require inspection or replacement. They make it easier to identify compatible part references for the engine, fuel system, lubrication, cooling and electrical equipment.
Volvo penta aqd70c engine specifications- Displacement: 6.73 l corresponding to the stated total engine displacement
- Category: 6-cylinder according to the number of cylinders specified for this engine
- Direct injection used to supply fuel to the engine
- Power: 184 kW (250 HP) according to the supplied technical specifications
- Fuel: diesel with four-stroke operation
View exploded diagrams Volvo penta aqd70c
