Parts and exploded diagrams for Volvo Penta 7.4gsixncb engine

This page allows you to view the exploded diagrams for the 7.4gsixncb Inboard engine, belonging to the 8-cylinder category, and easily identify the compatible parts for your engine.

Volvo Penta specialises in marine engine and propulsion solutions. These exploded diagrams make it easier to identify the components and part numbers required to maintain and repair Inboard engines.

Un doute? > contact us

Select an exploded diagram for your Volvo Penta 7.4gsixncb inboard engine

7.4gsixncb

The Volvo Penta 7.4gsixncb is a gasoline-powered Inboard marine engine in the 8-cylinder category. Its 7.4-litre displacement, equivalent to 7,400 cm³, is combined with a design intended to provide consistent propulsion in a variety of boating conditions.

Its maximum engine speed reaches 5,000 RPM, while its stated dry weight is 548 kg. The fuel injection system contributes to combustion management, and the marine-oriented design addresses onboard installation, operation and routine servicing requirements.

Exploded diagrams help locate the engine assemblies and clarify how their components fit together. They provide a practical basis for finding compatible parts and checking the part numbers required when preparing maintenance or repair work on the 7.4gsixncb.

7.4gsixncb engine specifications

Category: 8-cylinder for smooth mechanical power delivery
Displacement: 7.4 litres corresponding to a capacity of 7,400 cm³
Fuel: gasoline with a configuration suited to marine propulsion
Maximum engine speed: 5,000 RPM according to the supplied technical information
Dry weight: 548 kg to be considered when installing the engine

View exploded diagrams 7.4gsixncb

View all compatible parts
