Honda Marine
Parts and exploded diagrams for Volvo penta 7.4glplke engine
This page allows you to view the exploded diagrams for the Volvo penta 7.4glplke Inboard engine, belonging to the 8-cylinder category, and easily identify the compatible parts for your engine.
Volvo Penta is a brand specializing in marine propulsion solutions. These exploded diagrams make it easier to identify the components and references required to maintain and repair Inboard engines.
Select an exploded diagram for your Volvo penta 7.4glplke inboard engine
Volvo penta 7.4glplke
The Volvo penta 7.4glplke is an 8-cylinder gasoline Inboard engine. Its stated output of 330 HP, or 246 kW, is combined with a displacement of 7.40 litres for marine propulsion applications.
This V8 configuration has a 108.0 mm bore, a 101.6 mm stroke and a 9.3:1 compression ratio. Correctly locating the fuel, lubrication, cooling and exhaust components helps prepare maintenance work on the engine.
Exploded diagrams provide a clear way to locate each component before servicing. They also help users check references and select compatible parts for routine maintenance or engine repairs.
Volvo penta 7.4glplke engine specifications- Category: 8-cylinder with a confirmed V8 configuration
- Output: 330 HP (246 kW) stated for this engine
- Displacement: 7.40 l for this gasoline marine engine
- Bore and stroke: 108.0 × 101.6 mm according to the supplied dimensions
- Compression ratio: 9.3:1 based on the provided specifications
View exploded diagrams Volvo penta 7.4glplke
