Parts and exploded diagrams for Volvo penta 7.4glplkd engine

Request a quote

Request a return

Parts and exploded diagrams for Volvo penta 7.4glplkd engine

This page allows you to view the exploded diagrams for the Volvo penta 7.4glplkd Inboard engine, belonging to the 8-cylinder category, and easily identify the compatible parts for your engine.

Volvo Penta specialises in marine propulsion solutions. These exploded diagrams make it easier to identify the components and references required for the maintenance and repair of Inboard engines.

Un doute? > contact us

Select an exploded diagram for your Volvo penta 7.4glplkd inboard engine

Volvo penta 7.4glplkd

The Volvo penta 7.4glplkd is an 8-cylinder Inboard engine producing 246 kW (330 HP). Its 7.40 l displacement and V8 configuration correspond to the technical characteristics of the 7.4 GL engine.

This engine has a 108.0 mm x 101.6 mm bore and stroke together with a 9.3:1 compression ratio. The supplied documentation indicates a production period from 1993 to 1997 and lists the Volvo Penta 7.4 GL/DP-S drive variant.

Exploded diagrams provide a clear view of the mechanical assemblies before servicing begins. They help users compare components, locate the correct references for the Volvo penta 7.4glplkd and select compatible parts for maintenance or repair work.

Volvo penta 7.4glplkd engine specifications

Power: 246 kW (330 HP) delivered by this marine engine
Displacement: 7.40 l distributed across eight cylinders
Configuration: V8 as confirmed by the technical information
Bore and stroke: 108.0 mm x 101.6 mm according to the stated internal dimensions
Compression ratio: 9.3:1 based on the supplied specifications

View exploded diagrams Volvo penta 7.4glplkd

View all compatible parts
