Parts and exploded diagrams for Volvo penta 7.4glincs engine

Request a quote

Request a return

Parts and exploded diagrams for Volvo penta 7.4glincs engine

This page allows you to view the exploded diagrams for the Volvo penta 7.4glincs Inboard engine, which belongs to the 8-cylinder category, and easily identify the compatible parts for your engine.

Volvo Penta is a brand specialising in marine propulsion solutions. These exploded diagrams make it easier to identify the components and references required to maintain and repair Inboard engines.

Un doute? > contact us

Select an exploded diagram for your Volvo penta 7.4glincs inboard engine

Volvo penta 7.4glincs

The Volvo penta 7.4glincs is a gasoline-powered Inboard marine engine in the 8-cylinder category. Its 7.40 l displacement is combined with a stated output of 330 HP, or 246 kW, for marine propulsion applications.

Its V8 configuration features a 108.0 mm bore, a 101.6 mm stroke and a 9.3:1 compression ratio. Regular inspection of the lubrication, fuel, cooling and exhaust components helps ensure that maintenance work is planned accurately.

Exploded diagrams show how the individual Volvo penta 7.4glincs components are positioned before servicing begins. They provide useful support for identifying part numbers and selecting compatible parts for engine maintenance and repair.

Volvo penta 7.4glincs engine specifications

Category: 8-cylinder with an explicitly specified V8 configuration
Output: 330 HP (246 kW) stated for this marine engine
Displacement: 7.40 l distributed across its eight cylinders
Bore and stroke: 108.0 mm / 101.6 mm according to the specified internal dimensions
Compression ratio: 9.3:1 based on the supplied specifications

View exploded diagrams Volvo penta 7.4glincs

View all compatible parts
