Parts and exploded diagrams for Volvo penta 2002ag engine
This page allows you to view the exploded diagrams for the Volvo penta 2002ag Inboard engine, belonging to the 2-cylinder category, and easily identify compatible parts for your engine.
Volvo Penta is a brand specialising in marine propulsion solutions. These exploded diagrams help identify the components and references required for the maintenance and repair of Inboard engines.
Select an exploded diagram for your Volvo penta 2002ag inboard engine
Volvo penta 2002ag
The Volvo penta 2002ag is presented as a 4-stroke direct-injection diesel Inboard engine in the 2-cylinder category. The available data specifies an output of 18 HP (13 kW) at the propeller shaft, together with a displacement of 0.85 dm³ and an inline twin-cylinder configuration.
It runs on diesel fuel and uses a mechanically controlled injection system. The stated maximum operating speed is 3200 rpm, while idle speed is specified at 850 rpm, providing useful reference values when checking engine operation during maintenance.
The exploded diagrams for the Volvo penta 2002ag make it easier to locate assemblies and compatible parts before servicing. They help identify references relating to systems such as fuel supply, cooling, lubrication and electrical equipment when preparing a repair or component replacement.
Volvo penta 2002ag engine characteristics- Power: 18 HP (13 kW) delivered at the propeller shaft
- Displacement: 0.85 dm³ for this 2-cylinder engine category
- Direct injection with a mechanically controlled injection system
- Maximum speed: 3200 rpm with an indicated idle speed of 850 rpm
- Fuel: diesel used by this 4-stroke Inboard engine
View exploded diagrams Volvo penta 2002ag
