MAGNUS-style boat hatch and access cover

Escape hatches - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke†colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 4.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 679 x 679.

Cut-out dimensions C x D (in mm): 627 x 627.

Escape hatches - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke†colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 4.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 559 x 559.

Cut-out dimensions C x D (in mm): 507 x 507.

Deck hatches - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke†colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 559 x 429.

Cut-out dimensions C x D (in mm): 507 x 377.

Escape hatches - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke†colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 552 x 552.

Cut-out dimensions C x D (in mm): 470 x 470.

Deck hatches - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke†colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 509 x 379.

Cut-out dimensions C x D (in mm): 457 x 327.

Deck hatches - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke†colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 473 x 473.

Cut-out dimensions C x D (in mm): 421 x 421.

Ventilation hatch - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke†colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 1.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 312 x 3120

Cut-out dimensions C x D (in mm): 260 x 260.
