HY100 TYPE ENGINE MOUNT (EACH) - SHORE 40
RÉF. DM_VE_HY100
| VETUS
For heavy duty engines with 4 or more cylinders.
This type is extremely suitable for use with marine diesel engines in the power range between 30 and 125 kW (40-170 hp), due to low stiffness combined with high rigidity in the longitudinal direction.
Stiffness ratio:
Vertical: 1
Lateral: 1.2
Longitudinal: 3.5
Minimum load (Static): 40Kg
Minimum Compression (Static): 2 mm
Maximum load (Static + Dynamic): 100 Kg
Maximum compression (Static + Dynamic): 5mm
Shore 40
Pièce non en stock.
Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».
Un conseiller traitera votre demande dans la journée.
On demand
110.5
€110.50 VAT included
€92.08 VAT excluded
