Vetus Anti-Siphon Elbows for Marine Engines

Catégories

Vetus Anti-Siphon Elbows for Marine Engines

Prevents Backflow of Water into the Engine

What is a Vetus anti-siphon elbow?

The Vetus anti-siphon elbow prevents water backflow into the engine by breaking the siphon effect when the engine is shut off. It is essential in marine exhaust or cooling systems to protect the engine from flooding.

When should it be replaced?

Replace it if cracks, internal wear, clogging, or valve failure are detected. Annual inspection is recommended for continued protection.

Compatible with Vetus systems

DAM Marine offers anti-siphon elbows in marine-grade plastic, compatible with various hose sizes and resistant to heat, salt, and vibration.

Un doute? > contact us

8 item(s)

ANTI-SIPHON ELBOW TYPE ASD 13/19/25/32 MM WITH VALVE

RÉF. ASDV | VETUS

Anti-siphon elbow without valve and with hose. Supplied with ventilation pipe, connection 13 - 32 mm.

Can be used as a drainage system or toilet.

Interchangeable with the AIRVENT type and have the same fixing center distances.

Comes complete with fitting, hose clamps and 2m of hose. Non-valve anti-siphon elbows must be fitted with a ventilation pipe.

The air vent fitting rotates 360°. (Includes a 2 m hose and skin fittings). In addition, the valve can be serviced without removing the vent from the wall and no tools are required for this. For replacement, a set of 5 valves is available as a spare part.

A 13 mm diameter flexible hose can be directly connected to the elbow connections

Can be connected to pipes with inner diameters of 13, 19, 25 and 32 mm.

Size :

Width (mm): 68.

Length (mm): 96.

Height (mm): 133.

Livraison express → Monday 23 June

Livraison classique → Wednesday 25 June

Commandez dans les

00 h 00 m 00 s

Disponible

€126.00 VAT included

€105.00 VAT excluded

ANTI-SIPHON ELBOW WITH VALVE

RÉF. AIRVENTV | VETUS

Anti-siphon device with pressure relief valve without ventilation line. Supplied with connector, hose clamps and 4 m of 8 x 14 mm hose.

Can be used as an exhaust system or toilet.

Can be connected to pipes with internal diameters of 13, 19, 25 and 32 mm.

A 13mm diameter pipe can be directly fitted to the elbow fittings.

Size :

Width (mm): 50.

Length (mm): 98.

Height (mm): 162.

Materials:

Elbow, seat, valve and edge outlet: synthetic material.

Spring: Stainless steel.

Livraison express → Monday 23 June

Livraison classique → Wednesday 25 June

Commandez dans les

00 h 00 m 00 s

Disponible

€126.00 VAT included

€105.00 VAT excluded

REPLACEMENT FLAP FOR AIRVENT

RÉF. DM_VE_AV006 | VETUS

Replacement valve for the AIRVENTV range.

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand

€19.54 VAT included

€16.28 VAT excluded

ANTI-SIPHON ELBOW WITH AIR INTAKE PIPE AND THRU-HULL

RÉF. AIRVENTH | VETUS

Valveless anti-siphon device with ventilation line. Supplied with connector, hose clamps and 4 m of 8 x 14 mm hose.

Can be used as an exhaust system or toilet.

Can be connected to pipes with internal diameters of 13, 19, 25 and 32 mm.

A 13mm diameter pipe can be directly fitted to the elbow fittings.

Size :

Width (mm): 50.

Length (mm): 98.

Height (mm): 162.

Materials:

Elbow, seat, valve and edge outlet: synthetic material.

Spring: Stainless steel.

Livraison express → Monday 23 June

Livraison classique → Wednesday 25 June

Commandez dans les

00 h 00 m 00 s

Disponible

€126.00 VAT included

€105.00 VAT excluded

REPLACEMENT VALVE KIT FOR ASDV/H

RÉF. DM_VE_ASDVS | VETUS

Replacement kit (set of 5) of valve for ASDV model.

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand

€27.10 VAT included

€22.58 VAT excluded

ANTI-SIPHON ELBOW TYPE ASD 13/19/25/32 MM WITH PIPE

RÉF. DM_VE_ASDH | VETUS

Anti-siphon elbow without valve and with ventilation pipe, connection 13 - 32 mm.

Can be used as a drainage system or toilet.

Interchangeable with the AIRVENT type and have the same fixing center distances

Comes complete with fitting, hose clamps and 2m of hose. Non-valve anti-siphon elbows must be fitted with a ventilation pipe.

A 13 mm diameter flexible hose can be directly connected to the elbow connections

Can be connected to pipes with inner diameters of 13, 19, 25 and 32 mm.

Size :

Width (mm): 68.

Length (mm): 96.

Height (mm): 133.

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand

€126.00 VAT included

€105.00 VAT excluded

ANTI-SIPHON ELBOW TYPE ASD 38 MM WITH VALVE

RÉF. DM_VE_ASD38V | VETUS

Anti-siphon elbow with valve and hose. With 4m of 8 x 14mm ventilation hose, suitable for 38mm pipes. Ideal for toilets or holding tanks installed below the waterline.

Interchangeable with AIRVENT type thanks to the same fixing hole centers.

The air bleed fitting rotates 360°. (Includes 2m hose and skin fittings)

A 38 mm diameter flexible hose can be connected directly to the elbow connections. Mount each hose connection with a stainless steel clamp.

Size :

Length (mm): 129.

Width (mm): 48.

Height (mm): 107.

Pipe connection diameter (mm): 38.

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand

€126.00 VAT included

€105.00 VAT excluded
