SUPPORTS MOTEUR FLEXIBLES VETUS

|
15 item(s)
HYDRAULIC MOTOR SUPPORT...

HYDRAULIC MOTOR SUPPORT (EACH) - SHORE 45

RÉF. DM_VE_MITSTEUN | VETUS

For marine diesel engines from 18 to 26 kW (25-35 hp).

This HYDRO DAMPER is a combination of a classic rubber-metal damper and a hydraulic damper. Its vibration and noise reduction is truly astonishing. The maximum static load per support is 60 kg and the maximum thrust is 50 kg.

Stiffness ratio:

Vertical: 1

Lateral: 1

Longitudinal: 1

Minimum load (Static): 25Kg

Minimum Compression (Static): 1.3 mm

Maximum load (Static + Dynamic): 67 Kg

Maximum Compression (Static + Dynamic): 4.5mm

Shore 45

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
348.5 €348.50 VAT included
€290.42 VAT excluded
VETUS VETUS
Quantity
Voir le produit
FLEXIBLE ENGINE SUPPORT...

FLEXIBLE ENGINE SUPPORT TYPE LMX500 (EACH) - SHORE 65

RÉF. DM_VE_LMX500 | VETUS

For marine diesel engines from 70 to 350 kW (95-480 hp).

This type was designed with particular regard to the power-to-weight ratio of modern diesel engines. The weight of an engine, in relation to its thrust, has become lower. The LMX type guarantees optimal vibration damping, even at idle. It has very high horizontal and rear rigidity, which allows acceptance

of a considerable thrust.

Vibration damping in horizontal turns is also excellent.

Stiffness ratio:

Vertical: 1

Lateral: 1

Longitudinal: 7

Minimum load (Static): 300Kg

Minimum Compression (Static): 3 mm

Maximum load (Static + Dynamic): 500 Kg

Maximum compression (Static + Dynamic): 5mm

Shore 65

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
278 €278.00 VAT included
€231.67 VAT excluded
VETUS VETUS
Quantity
Voir le produit
FLEXIBLE ENGINE SUPPORT...

FLEXIBLE ENGINE SUPPORT TYPE LMX340 (EACH) - SHORE 55

RÉF. DM_VE_LMX340 | VETUS

For marine diesel engines from 70 to 350 kW (95-480 hp).

This type was designed with particular regard to the power-to-weight ratio of modern diesel engines. The weight of an engine, in relation to its thrust, has become lower. The LMX type guarantees optimal vibration damping, even at idle. It has very high horizontal and rear rigidity, which allows acceptance

of a considerable thrust.

Vibration damping in horizontal turns is also excellent.

Stiffness ratio:

Vertical: 1

Lateral: 1

Longitudinal: 7

Minimum load (Static): 205Kg

Minimum Compression (Static): 3 mm

Maximum load (Static + Dynamic): 340 Kg

Maximum compression (Static + Dynamic): 5mm

Shore 55

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
278 €278.00 VAT included
€231.67 VAT excluded
VETUS VETUS
Quantity
Voir le produit
FLEXIBLE ENGINE SUPPORT...

FLEXIBLE ENGINE SUPPORT TYPE LMX210 (EACH) - SHORE 45

RÉF. DM_VE_LMX210 | VETUS

For marine diesel engines from 70 to 350 kW (95-480 hp).

This type was designed with particular regard to the power-to-weight ratio of modern diesel engines. The weight of an engine, in relation to its thrust, has become lower. The LMX type guarantees optimal vibration damping, even at idle. It has very high horizontal and rear rigidity, which allows acceptance

of a considerable thrust.

Vibration damping in horizontal turns is also excellent.

Stiffness ratio:

Vertical: 1

Lateral: 1

Longitudinal: 7

Minimum load (Static): 125Kg

Minimum Compression (Static): 3 mm

Maximum load (Static + Dynamic): 210 Kg

Maximum compression (Static + Dynamic): 5mm

Shore 45

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
249 €249.00 VAT included
€207.50 VAT excluded
VETUS VETUS
Quantity
Voir le produit
K80V TYPE ENGINE MOUNT (EACH)

K80V TYPE ENGINE MOUNT (EACH)

RÉF. DM_VE_KSTEUN80V | VETUS

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
75.5 €75.50 VAT included
€62.92 VAT excluded
VETUS VETUS
Quantity
Voir le produit
FLEXIBLE ENGINE SUPPORT...

FLEXIBLE ENGINE SUPPORT TYPE LMX140 (EACH) - SHORE 35

RÉF. DM_VE_LMX140 | VETUS

For marine diesel engines from 70 to 350 kW (95-480 hp).

This type was designed with particular regard to the power-to-weight ratio of modern diesel engines. The weight of an engine, in relation to its thrust, has become lower. The LMX type guarantees optimal vibration damping, even at idle. It has very high horizontal and rear rigidity, which allows acceptance

of a considerable thrust.

Vibration damping in horizontal turns is also excellent.

Stiffness ratio:

Vertical: 1

Lateral: 1

Longitudinal: 7

Minimum load (Static): 85Kg

Minimum Compression (Static): 3 mm

Maximum load (Static + Dynamic): 140 Kg

Maximum compression (Static + Dynamic): 5mm

Shore 35

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
249 €249.00 VAT included
€207.50 VAT excluded
VETUS VETUS
Quantity
Voir le produit
K75V TYPE ENGINE MOUNT (EACH)

K75V TYPE ENGINE MOUNT (EACH)

RÉF. DM_VE_KSTEUN75V | VETUS

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
75.5 €75.50 VAT included
€62.92 VAT excluded
VETUS VETUS
Quantity
Voir le produit
Back to top
15 item(s)
